YOKOGAWA S9361DH-00 Terminal Board Module new brand

YOKOGAWA S9361DH-00
Technical Specifications
Brand: YOKOGAWA (Yokogawa Electric Corporation)
Model: S9361DH-00
Dimensions: 100 mm × 120 mm × 25 mm (3.94 in × 4.72 in × 0.98 in)
Weight: Approximately 0.3 kg (0.66 lbs)
Country of Origin: Japan
HS Code: 85371091 (industrial control module / DCS terminal board)
Operating Temperature: 0°C to +55°C
Storage Temperature: -20°C to +65°C
Power Supply: 24 V DC (industrial standard, ±10% tolerance)
Protection Rating: IP20 (dust and solid particle protection)
Certifications: CE compliant (electromagnetic compatibility and safety)
Mounting: Panel/rack mountable for control cabinet installation
Construction: Industrial-grade printed circuit board (PCB) with screw terminal interface
Product Status: Active (long-term supply and technical support available)

Key Characteristics
CENTUM DCS Compatibility: Exclusively designed for Yokogawa CENTUM series systems, ensuring plug-and-play integration and optimal performance.
Compact Design: Small form factor (100×120×25 mm) and lightweight (0.3 kg) for space-efficient installation in dense control cabinets.
Industrial Reliability: Robust PCB construction and IP20 protection for stable operation in harsh industrial environments.
Wide Temperature Range: Operates reliably from 0°C to 55°C, with storage tolerance from -20°C to 65°C for global deployment.
EMI Resistance: Superior electromagnetic interference immunity for stable signal transmission in industrial settings.
Easy Installation: Screw terminal interface simplifies field wiring and maintenance, reducing installation time.
CE Certified: Complies with European safety and EMC standards for global industrial use.
Long-Term Support: Active product lifecycle with ongoing supply and technical assistance.
