XV-303-15-C00-A00-1B EATON Human Machine Interface (HMI)

EATON XV-303-15-C00-A00-1B
Brand: Eaton (Cutler-Hammer)
Model: XV-303-15-C00-A00-1B
Series: XV-300 Advanced HMI / Touch Panel
Type: 15.4-inch PCT Capacitive Multi-Touch Operator Interface
Dimensions: 403.7 mm (L) × 254.9 mm (W) × 76.6 mm (H)
Weight: 3.9 kg (≈8.6 lbs)
Country of Origin: Germany
HS Code: 8537109000 (Industrial HMI/Touch Panel)
Operating Temperature: 0°C to 50°C
Storage Temperature: -20°C to 60°C
Input Power: 24 VDC (19.2–28.8 VDC), 0.6 A
Output: No analog/digital I/O; communication-only interface

Features:
15.4-inch PCT (Projected Capacitive) multi-touch widescreen display
800 MHz ARM Cortex-A9 processor with high-performance GPU
512 MB DRAM, 1 GB internal flash, 120 KB retain memory for PLC
Dual independent 10/100 Mbps Ethernet ports; supports RS-232, RS-485, CAN, USB Host/Device
SD card slot for memory expansion and system updates
Front IP65 / NEMA 12 protection; toughened anti-reflective glass
Linux OS; compatible with Eaton Galileo / VisualDesigner software
Sleek, tablet-like industrial design; supports portrait/landscape orientation
DNV GL, EN 50178, IEC/EN 61131-2, EMC (2014/30/EU), CUL certified



interface
*Output method: rear output
*Fast Ethernet: 3 slots, each slot supports 8 ports, with optional optical and electrical options
*Gigabit Ethernet: Provides 4 1000Base SFP slots
*CONSOLE port: RS232 (RJ45)
*Alarm port: 5.08mm spacing 3-pin Phoenix wiring terminal, 250VAC/220VDC 2 A
cable
*Twisted pair cable: 100m
*Multimode fiber: 1310nm, 2km (100Mbps); 1310nm, 500m (gigabit)
*Single mode fiber: 1310nm, 0-40km; 1550nm, 0-80km
source
*Input voltage: 110-220VDC/VAC, redundant input
*Connection terminal: 5.08mm spacing 5-pin Phoenix wiring terminal
*Power:<40W
mechanical properties
*Case: Aluminum model with fanless design
*Protection level: IP30
*Installation method: 19 inch 1U rack type
*Shell size: 440 mm * 44.5 mm * 370 mm (W * H * D), as shown in the attached image
*Impact, vibration, and drop: meet the requirements of IEC61850-3 5.5 CM level
*Weight: approximately 4.3kg

*10 Mbps forwarding speed: 14881pps
*100Mbps forwarding speed: 148810pps
*Transmission method: storage and forwarding
*System exchange bandwidth: 1.6Gbps
*Cache size: 1Mbits
*MAC address table: 2K
