VMF-RLC16-V111 200-570-101-015 200-570-000-111 Vibro-meter DCS board

Vibro-meter VMF-RLC16-V111 200-570-101-015 & 200-570-000-111 – Product Description & Technical Specifications
Product Description
The Vibro-meter VMF-RLC16-V111 200-570-101-015 and 200-570-000-111 are 16-channel relay expansion cards, key components of Vibro-meter’s VM600 Machinery Protection and Condition Monitoring System under Meggitt PLC. These modules are designed as optional relay cards to expand the relay capacity of the VM600 system, particularly when the built-in relays of IOC4T input/output modules are insufficient for industrial applications. They provide high-density relay control for actuators, alarm systems, and safety circuits, enabling fail-safe operation and reliable status feedback for critical rotating machinery. Widely used in power generation, oil and gas, and heavy industrial sectors, these relay cards integrate seamlessly with VM600 system racks, supporting vibration monitoring, turbine protection, and distributed I/O architectures to ensure stable and safe equipment operation.

Basic Information
Brand: Vibro-meter (a brand under Meggitt PLC)
Models: VMF-RLC16-V111 200-570-101-015; VMF-RLC16-V111 200-570-000-111
Product Type: 16-Channel Relay Expansion Card; SPDT Relay Module for VM600 Series
Series: Vibro-meter VM600 Series
Weight: Approximately 0.5 kg (consistent with VM600 series modular relay card design)
Dimensions: 150 mm × 100 mm × 30 mm; compatible with 19-inch rack mounting (fits VM600 system chassis and slimline racks)
Country of Origin: Switzerland (original manufacturing location for Vibro-meter core components)
HS Code: 90278090 (for reference only; applicable to industrial vibration monitoring instruments and their components)
Temperature Specifications
Operating Temperature: -10 °C to +50 °C (optimized for cabinet installation in industrial control environments)
Storage Temperature: -20 °C to +60 °C (safe for long-term storage without component degradation or relay damage)
Humidity: 5% to 95% RH (non-condensing); adaptable to standard industrial operating conditions
Input Specifications
Power Input: 220 V AC (nominal); compatible with standard industrial power systems; power consumption up to 15 W
Bus Interface: Integrates with VM600 system bus; supports communication with VM600 CPU modules for relay control and status feedback
Control Input: Accepts logic control signals from VM600 CPU or IOC modules; jumper-selectable relay driver inverter logic for flexible configuration
Input Protection: Full input/output isolation; integrated anti-electromagnetic interference (EMI) design to ensure stable operation in industrial electrical environments
Output Specifications
Relay Output: 16 SPDT (Single Pole Double Throw) relays; contact capacity of 300 VDC @ 0.35 A / 250 VAC @ 5 A for reliable control of external devices
Communication Output: Real-time status feedback to VM600 system bus; enables remote monitoring of relay operation and fault detection
Status Output: Front-panel LED indicators for each relay’s operational status (energized/de-energized); simplifies on-site diagnostics and maintenance
Terminal Output: 3×16 screw terminals for robust wiring; ensures secure connection and easy installation/termination
Key Features
High-Density Relay Capacity: 16 SPDT relays in a compact form factor, providing expanded relay control for VM600 machinery protection systems
Flexible Logic Control: Jumper-selectable relay driver inverter logic, adapting to different system control requirements
Hot-Swappable Design: Supports live insertion and removal, minimizing system downtime during maintenance or reconfiguration
Robust Construction: Low contact resistance and low capacitance; electrical lifespan of 100,000 operations for long-term reliability
Seamless Integration: Fully compatible with VM600 system racks and other VM600 series modules (e.g., IOC4T, CPUM) for scalable system expansion
Easy Installation: Screw-terminal connectors for secure wiring; compact size ensures space-efficient rack mounting
Certifications: Complies with CE EMC standards; meets global industrial safety and quality requirements for relay control modules

interface
*Output method: rear output
*Fast Ethernet: 3 slots, each slot supports 8 ports, with optional optical and electrical options
*Gigabit Ethernet: Provides 4 1000Base SFP slots
*CONSOLE port: RS232 (RJ45)
*Alarm port: 5.08mm spacing 3-pin Phoenix wiring terminal, 250VAC/220VDC 2 A
cable
*Twisted pair cable: 100m
*Multimode fiber: 1310nm, 2km (100Mbps); 1310nm, 500m (gigabit)
*Single mode fiber: 1310nm, 0-40km; 1550nm, 0-80km
source
*Input voltage: 110-220VDC/VAC, redundant input
*Connection terminal: 5.08mm spacing 5-pin Phoenix wiring terminal
*Power:<40W
mechanical properties
*Case: Aluminum model with fanless design
*Protection level: IP30
*Installation method: 19 inch 1U rack type
*Shell size: 440 mm * 44.5 mm * 370 mm (W * H * D), as shown in the attached image
*Impact, vibration, and drop: meet the requirements of IEC61850-3 5.5 CM level
*Weight: approximately 4.3kg

*10 Mbps forwarding speed: 14881pps
*100Mbps forwarding speed: 148810pps
*Transmission method: storage and forwarding
*System exchange bandwidth: 1.6Gbps
*Cache size: 1Mbits
*MAC address table: 2K
