Vibro-Meter VMF-RLC16-V111 200-570-101-015 / 200-570-000-111
Product Introduction
The Vibro-Meter VMF-RLC16-V111 is a high-performance relay card module belonging to the VM600 series machinery protection system, designed for industrial vibration monitoring and rotating machinery protection. It is primarily used in power generation, petrochemical, petroleum, and marine applications to provide reliable relay output control for vibration monitoring systems. This module integrates seamlessly into 19-inch rack-mounted systems, offering robust performance for critical industrial monitoring tasks.

Technical Parameters
Brand: Vibro-Meter (Meggitt Sensing Systems)
Model: VMF-RLC16-V111; Part Numbers: 200-570-101-015, 200-570-000-111
Weight: 0.34 kg (approximate)
Dimensions: 234 mm × 113 mm × 20 mm (W×H×D)
Country of Origin: Sweden
HS Code: 8538900000
Operating Temperature: -20°C to +70°C
Storage Temperature: -40°C to +85°C
Power Supply: 24 V DC / 28 V DC
Input: 16 analog vibration signal input channels; compatible with standard vibration sensors
Output: 16 relay output channels; provides dry contact relay signals for alarm and control functions
Communication Interface: RS-485 (Modbus RTU compatible)
Sampling Rate: 16,000 samples per second
Resolution: 16-bit ADC
Frequency Response: 0.1 Hz to 5 kHz
Accuracy: ±0.01%
Protection Rating: Industrial-grade, suitable for harsh industrial environments
Certifications: CE, RoHS compliant
Key Features: 16-channel relay output for multi-point monitoring; high-precision vibration signal processing; wide operating temperature range; robust design for industrial durability; easy integration into VM600 system racks; supports redundant power supply configurations

interface
*Output method: rear output
*Fast Ethernet: 3 slots, each slot supports 8 ports, with optional optical and electrical options
*Gigabit Ethernet: Provides 4 1000Base SFP slots
*CONSOLE port: RS232 (RJ45)
*Alarm port: 5.08mm spacing 3-pin Phoenix wiring terminal, 250VAC/220VDC 2 A
cable
*Twisted pair cable: 100m
*Multimode fiber: 1310nm, 2km (100Mbps); 1310nm, 500m (gigabit)
*Single mode fiber: 1310nm, 0-40km; 1550nm, 0-80km
source
*Input voltage: 110-220VDC/VAC, redundant input
*Connection terminal: 5.08mm spacing 5-pin Phoenix wiring terminal
*Power:<40W
mechanical properties
*Case: Aluminum model with fanless design
*Protection level: IP30
*Installation method: 19 inch 1U rack type
*Shell size: 440 mm * 44.5 mm * 370 mm (W * H * D), as shown in the attached image
*Impact, vibration, and drop: meet the requirements of IEC61850-3 5.5 CM level
*Weight: approximately 4.3kg

*10 Mbps forwarding speed: 14881pps
*100Mbps forwarding speed: 148810pps
*Transmission method: storage and forwarding
*System exchange bandwidth: 1.6Gbps
*Cache size: 1Mbits
*MAC address table: 2K
