VMF-IOCN 200-566-101-013 200-566-000-112 VIBRO METER Input/Output Control
The Vibro-Meter VMF-IOCN (VM600 IOCN) is a Input/Output Control Network module belonging to the VM600 series machinery protection and condition monitoring system. It serves as a critical communication gateway and I/O interface card, designed for seamless integration into industrial rotating machinery monitoring setups, including turbines, generators, compressors, and pumps. This module enables data acquisition, signal processing, and communication between field sensors, protection cards, and higher-level control systems (DCS/PLC), supporting reliable real-time monitoring, alarm handling, and predictive maintenance.
Vibro-Meter VMF-IOCN (VM600 IOCN, 200-566-101-013 / 200-566-000-112) Product Introduction The Vibro-Meter VMF-IOCN (VM600 IOCN) is a Input/Output Control Network module belonging to the VM600 series machinery protection and condition monitoring system. It serves as a critical communication gateway and I/O interface card, designed for seamless integration into industrial rotating machinery monitoring setups, including turbines, generators, compressors, and pumps. This module enables data acquisition, signal processing, and communication between field sensors, protection cards, and higher-level control systems (DCS/PLC), supporting reliable real-time monitoring, alarm handling, and predictive maintenance. Technical Parameters Brand: Vibro-Meter (Meggitt Sensing Systems) Model: VMF-IOCN (VM600 IOCN); Part Numbers: 200-566-101-013, 200-566-000-112 Weight: 0.36 kg (approximate) Dimensions: 267 mm × 133 mm × 25 mm (W×H×D, standard 19-inch rack-mountable) Country of Origin: United States HS Code: 8538900000 Operating Temperature: -20°C to +70°C Storage Temperature: -40°C to +85°C Power Supply: 24 V DC (rack-powered via VM600 backplane) Input: Mixed analog (IEPE/ICP compatible vibration sensors) and digital input channels; supports dynamic vibration, displacement, and speed signals Output: Analog (4–20 mA, 0–10 VDC) and digital relay outputs; configurable for alarm and control signaling Communication Interfaces: 100 Mbps Ethernet (2 ports), RS-232/RS-422/RS-485 serial (up to 3 ports); supports Modbus RTU/TCP, PROFINET, and DNP3 protocols Processor: ARM Cortex series Memory: Flash memory + RAM for configuration and data logging Frequency Response: 0.1 Hz to 10 kHz Sampling Rate: Up to 51.2 kHz per channel Key Features: Hot-swappable design for live maintenance; front-panel LED status indicators; compatible with all VM600 ABE04x system racks; supports one-shot configuration via VM600 MPSx software; robust industrial-grade construction for harsh environments; CE and RoHS compliant
interface *Output method: rear output *Fast Ethernet: 3 slots, each slot supports 8 ports, with optional optical and electrical options *Gigabit Ethernet: Provides 4 1000Base SFP slots *CONSOLE port: RS232 (RJ45) *Alarm port: 5.08mm spacing 3-pin Phoenix wiring terminal, 250VAC/220VDC 2 A cable *Twisted pair cable: 100m *Multimode fiber: 1310nm, 2km (100Mbps); 1310nm, 500m (gigabit) *Single mode fiber: 1310nm, 0-40km; 1550nm, 0-80km source *Input voltage: 110-220VDC/VAC, redundant input *Connection terminal: 5.08mm spacing 5-pin Phoenix wiring terminal *Power:<40W mechanical properties *Case: Aluminum model with fanless design *Protection level: IP30 *Installation method: 19 inch 1U rack type *Shell size: 440 mm * 44.5 mm * 370 mm (W * H * D), as shown in the attached image *Impact, vibration, and drop: meet the requirements of IEC61850-3 5.5 CM level *Weight: approximately 4.3kg
