Vibro-meter VMF-IOC4T 200560-101-017 & 200-560-000-111 – Product Description & Technical Specifications
Product Description
The Vibro-meter VMF-IOC4T 200560-101-017 and 200-560-000-111 are 4-channel input/output control modules, key components of Vibro-meter’s VM600 Machinery Protection and Condition Monitoring System under Meggitt PLC. These modules serve as a critical interface between the VM600 system’s central processing unit and field devices, enabling bidirectional signal transmission, on-site control, and status feedback for rotating machinery. They integrate input signal acquisition, output control, and fault monitoring functions, designed to work with vibration sensors, temperature probes, and control actuators in industrial settings. Widely used in turbines, generators, compressors, and pumps across oil and gas, power generation, and chemical sectors, they support real-time equipment control and predictive maintenance, ensuring stable and safe operation of industrial machinery.

Basic Information
Brand: Vibro-meter (a brand under Meggitt PLC)
Models: VMF-IOC4T 200560-101-017; VMF-IOC4T 200-560-000-111
Product Type: 4-Channel Input/Output (I/O) Control Module; System Interface Module for VM600 Series
Series: Vibro-meter VM600 Series
Weight: Approximately 0.12 kg to 0.18 kg (consistent with VM600 series modular design)
Dimensions: 2.2 cm × 12.4 cm × 12.6 cm; compatible with 19-inch rack mounting (fits VM600 system chassis)
Country of Origin: United States
HS Code: 90278090 (for reference only; applicable to industrial vibration monitoring instruments and their components)
Temperature Specifications
Operating Temperature: -20 °C to +70 °C (suitable for cabinet installation in harsh industrial environments)
Storage Temperature: -40 °C to +85 °C (safe for long-term storage without component degradation)
Humidity: 5% to 95% RH (non-condensing); adaptable to humid industrial operating conditions
Input Specifications
Power Input: +24 V DC (nominal); input range 18-30 V DC; dual redundant power input optional for enhanced reliability
Bus Interface: Supports Modbus RTU/TCP and RS-485 communication protocols; equipped with Ethernet port for data transmission to VM600 CPU module and upper control systems
Signal Input: 4 configurable analog input channels (0-10 V DC or 4-20 mA); accepts signals from vibration sensors, temperature probes, and pressure transducers; supports vibration displacement, velocity, and acceleration signal input as well as temperature monitoring (0-100 °C)
Input Protection: Integrated anti-electromagnetic interference (EMI) design; overvoltage, overcurrent, and reverse polarity protection; channel isolation to prevent cross-interference and ensure signal integrity

Output Specifications
Communication Output: High-speed data transmission via Ethernet and RS-485 interfaces; enables real-time data exchange with DCS, PLC, and VM600 CMS software for remote monitoring and control
Analog Outputs: 4 configurable analog outputs (4-20 mA or 0-10 V DC); transmits processed input signals and control commands to external actuators and monitoring devices
Status Output: Front-panel LED indicators for module power, communication, and channel fault status; 4 user-configurable relay outputs (SPDT) for alarm and control signals, with adjustable response time
Control Output: Supports on-site control signal output for actuator adjustment; compatible with external control devices, enabling manual and automatic control mode switching
Key Features
Dual-Function I/O Interface: 4 analog input channels for signal acquisition and 4 analog output channels for control signal transmission, realizing bidirectional data interaction between system and field devices
Broad Signal Compatibility: Accepts vibration, temperature, and pressure signals from various industrial sensors, suitable for multi-parameter monitoring of rotating machinery
Modular Integration: 19-inch rack-mountable, plug-and-play and hot-swappable design; fully compatible with VM600 series CPU modules and monitoring cards for flexible system expansion
Reliable Protection Performance: Strong anti-EMI capability and comprehensive input protection, ensuring stable operation in harsh industrial environments with power fluctuations and electrical interference
Flexible Configuration: All input/output channels are independently configurable; adjustable signal range, filter frequency, and alarm setpoints to adapt to different application requirements
Easy Maintenance: Front-panel status indicators and built-in self-test function for quick fault diagnosis; compatible with VM600 configuration software for remote parameter setting and data analysis
Certifications: Complies with CE, ATEX/IECEx (explosion-proof optional), and API 670 standards; meets global industrial safety and quality requirements for vibration monitoring and control systems

interface
*Output method: rear output
*Fast Ethernet: 3 slots, each slot supports 8 ports, with optional optical and electrical options
*Gigabit Ethernet: Provides 4 1000Base SFP slots
*CONSOLE port: RS232 (RJ45)
*Alarm port: 5.08mm spacing 3-pin Phoenix wiring terminal, 250VAC/220VDC 2 A
cable
*Twisted pair cable: 100m
*Multimode fiber: 1310nm, 2km (100Mbps); 1310nm, 500m (gigabit)
*Single mode fiber: 1310nm, 0-40km; 1550nm, 0-80km
source
*Input voltage: 110-220VDC/VAC, redundant input
*Connection terminal: 5.08mm spacing 5-pin Phoenix wiring terminal
*Power:<40W
mechanical properties
*Case: Aluminum model with fanless design
*Protection level: IP30
*Installation method: 19 inch 1U rack type
*Shell size: 440 mm * 44.5 mm * 370 mm (W * H * D), as shown in the attached image
*Impact, vibration, and drop: meet the requirements of IEC61850-3 5.5 CM level
*Weight: approximately 4.3kg

*10 Mbps forwarding speed: 14881pps
*100Mbps forwarding speed: 148810pps
*Transmission method: storage and forwarding
*System exchange bandwidth: 1.6Gbps
*Cache size: 1Mbits
*MAC address table: 2K
