VM600 PNR200-570-000-111 VIBRO METER controller module new in stock

Vibro-Meter VM600 RLC16 PNR 200-570-000-111
Product Introduction
The Vibro-Meter VM600 RLC16 (Part Number: 200-570-000-111) is a rack-mounted relay logic controller module for the VM600 series machinery protection and condition monitoring systems by Meggitt Sensing Systems. It provides 16 configurable SPDT relays and flexible logic control, serving as a critical interface for alarm signaling, equipment interlocking, and system control in industrial rotating machinery applications such as turbines, generators, compressors, and pumps. Designed for harsh industrial environments, it ensures reliable operation and seamless integration with VM600 monitoring systems and external control devices.

Technical Parameters
Brand: Vibro-Meter (Meggitt Sensing Systems)
Model: VM600 RLC16; Part Number: 200-570-000-111
Weight: Approximately 0.3 kg
Dimensions: 100 mm (W) × 90 mm (H) × 25 mm (D) (6U rack-mountable)
Country of Origin: Switzerland
HS Code: 8537101190
Operating Temperature: -20°C to +70°C
Storage Temperature: -40°C to +85°C
Power Supply: Powered via VM600 backplane; 24 VDC nominal
Input: Digital logic inputs from VM600 system modules; accepts alarm and status signals for logic processing
Output: 16 user-configurable SPDT (single-pole double-throw) relay outputs; configurable as normally energized (NE) or normally de-energized (NDE); relay contact rating: 5 A @ 250 VAC / 30 VDC
Communication Interfaces: VM600 backplane bus; supports Ethernet, Modbus TCP, RS-232, RS-485 for data transmission to PLCs, DCS, and monitoring systems
Programming: Supports IEC 61131-3 compliant programming languages; configurable via Vibro-Meter software tools
Key Features: 16 isolated relay outputs; hot-swappable design for easy maintenance; front-panel LED status indicators; high EMC immunity and surge protection; fully compatible with VM600 rack and system modules; CE, RoHS compliant

interface
*Output method: rear output
*Fast Ethernet: 3 slots, each slot supports 8 ports, with optional optical and electrical options
*Gigabit Ethernet: Provides 4 1000Base SFP slots
*CONSOLE port: RS232 (RJ45)
*Alarm port: 5.08mm spacing 3-pin Phoenix wiring terminal, 250VAC/220VDC 2 A
cable
*Twisted pair cable: 100m
*Multimode fiber: 1310nm, 2km (100Mbps); 1310nm, 500m (gigabit)
*Single mode fiber: 1310nm, 0-40km; 1550nm, 0-80km
source
*Input voltage: 110-220VDC/VAC, redundant input
*Connection terminal: 5.08mm spacing 5-pin Phoenix wiring terminal
*Power:<40W
mechanical properties
*Case: Aluminum model with fanless design
*Protection level: IP30
*Installation method: 19 inch 1U rack type
*Shell size: 440 mm * 44.5 mm * 370 mm (W * H * D), as shown in the attached image
*Impact, vibration, and drop: meet the requirements of IEC61850-3 5.5 CM level
*Weight: approximately 4.3kg

*10 Mbps forwarding speed: 14881pps
*100Mbps forwarding speed: 148810pps
*Transmission method: storage and forwarding
*System exchange bandwidth: 1.6Gbps
*Cache size: 1Mbits
*MAC address table: 2K
