VM-703B/NB1/CS1/TRP/TB1 DCS module

KONGSBERG VM-703B/NB1/CS1/TRP/TB1 Product Introduction
Brand: KONGSBERG
Model: VM-703B/NB1/CS1/TRP/TB1
Order No.: VM-703B/NB1/CS1/TRP/TB1
Product Name: Marine Vibration Monitoring Module
Origin: Norway
Customs HS Code: 9031809090

Dimensions (H×W×D): 240 × 130 × 40 mm
Weight: 0.55 kg
Input: Vibration probe / speed sensor signal input
Output: Analog/digital monitoring signal output, alarm relay output
Power Supply: DC 24 V, power consumption ≤ 8 W
Core Characteristics: Non-contact high-precision measurement; marine vibration-resistant design; fault self-diagnosis; data logging; DNV / LR marine certification; wide temperature range -40℃ ~ +75℃

interface
*Output method: rear output
*Fast Ethernet: 3 slots, each slot supports 8 ports, with optional optical and electrical options
*Gigabit Ethernet: Provides 4 1000Base SFP slots
*CONSOLE port: RS232 (RJ45)
*Alarm port: 5.08mm spacing 3-pin Phoenix wiring terminal, 250VAC/220VDC 2 A
cable
*Twisted pair cable: 100m
*Multimode fiber: 1310nm, 2km (100Mbps); 1310nm, 500m (gigabit)
*Single mode fiber: 1310nm, 0-40km; 1550nm, 0-80km
source
*Input voltage: 110-220VDC/VAC, redundant input
*Connection terminal: 5.08mm spacing 5-pin Phoenix wiring terminal
*Power:<40W
mechanical properties
*Case: Aluminum model with fanless design
*Protection level: IP30
*Installation method: 19 inch 1U rack type
*Shell size: 440 mm * 44.5 mm * 370 mm (W * H * D), as shown in the attached image
*Impact, vibration, and drop: meet the requirements of IEC61850-3 5.5 CM level
*Weight: approximately 4.3kg

*10 Mbps forwarding speed: 14881pps
*100Mbps forwarding speed: 148810pps
*Transmission method: storage and forwarding
*System exchange bandwidth: 1.6Gbps
*Cache size: 1Mbits
*MAC address table: 2K
