Vibro-meter VMF-MPC4 200-510-111-034 & 200-510-070-113 – Product Description & Technical Specifications
Product Description
The Vibro-meter VMF-MPC4 200-510-111-034 and 200-510-070-113 are four-channel eddy current sensor signal conditioning and processing modules, belonging to Vibro-meter’s MPC4 product line under Meggitt PLC. As core components of Vibro-meter’s Machinery Protection System (MPS®) and Condition Monitoring System (CMS), they are specifically designed to connect non-contact eddy current displacement probes. These modules perform high-precision measurement, processing, alarm, and signal output for key mechanical parameters of rotating machinery, including radial shaft vibration, axial displacement, key phasing (rotational speed), and eccentricity. They are widely used in turbines, gas turbines, compressors, generators, and other rotating equipment in oil and gas, power generation, and chemical industries, serving as a critical "nerve center" for equipment safe operation and a key data source for predictive maintenance.

Basic Information
Brand: Vibro-meter (a brand under Meggitt PLC)
Models: VMF-MPC4 200-510-111-034; VMF-MPC4 200-510-070-113
Product Type: Four-channel Eddy Current Sensor Signal Conditioner & Monitor Module
Series: Vibro-meter MPC4 Series
Weight: Approximately 0.1 kg (consistent with MPC4 series modular design)
Dimensions: 2.2 cm × 12.4 cm × 12.6 cm; compatible with 19-inch rack mounting (fits MPS2000 chassis and slimline racks)
Country of Origin: United States
HS Code: 90278090 (for reference only; applicable to industrial vibration monitoring instruments and their components)
Temperature Specifications
Operating Temperature: -20 °C to +70 °C (wide-temperature design, suitable for cabinet installation environments)
Storage Temperature: -40 °C to +85 °C (safe for long-term storage without component damage)
Humidity: 5% to 95% RH (non-condensing); adaptable to harsh industrial operating environments
Input Specifications
Power Input: +24 V DC (nominal); input range 18-30 V DC; dual redundant power input optional for enhanced reliability
Bus Interface: Standard RS-485/RS-422 serial interface; supports Modbus RTU protocol for configuration, data reading, and advanced diagnostics
Signal Input: 4 independent channels; each channel accepts -2V to -18V DC raw signals from eddy current probe preamplifiers (e.g., Vibro-meter 100/200 series); supports key phasing input for rotational speed measurement and vibration phase analysis
Input Protection: Integrated anti-electromagnetic interference (EMI) design; overvoltage and reverse polarity protection to prevent damage from power fluctuations and electrical anomalies
Output Specifications
Communication Output: High-speed data transmission via RS-485/RS-422 interface; compatible with DCS, PLC, and dedicated condition monitoring systems for remote monitoring and data recording
Analog Outputs: 4 configurable analog outputs (4-20 mA or 0-10 V DC) per module; 4-20 mA outputs correspond to measured values, 0-10 V DC outputs correspond to raw gap voltage or dynamic vibration signals
Status Output: 4 user-configurable relays for alarms (normally open/normally closed, SPDT) and 1 status relay; each channel has independent dual alarm setpoints (warning, danger) with adjustable response time
Measurement Output: Real-time transmission of radial shaft vibration (0-800 µm pk-pk typical), axial displacement (±2 mm typical), rotational speed, and eccentricity data; linearity better than ±1% F.S. for high measurement accuracy
Key Features
High-Precision Measurement: Equipped with high-performance digital signal processor (DSP) for real-time digital filtering, dynamic compensation, and peak-to-peak/gap voltage calculation, ensuring accurate reflection of mechanical status
Modular Design: 19-inch rack-mountable, plug-and-play modular structure; flexible combination in MPS2000 chassis to build large-scale monitoring systems from single to hundreds of channels
Reliable Protection: Follows "fail-safe" design principle; built-in self-test (BIST) for continuous module health monitoring; watchdog function triggers safe-state alarm in case of internal faults
Flexible Configuration: Each channel independently configurable via front-panel buttons or configuration software; adjustable measurement type, range, alarm values, and filter frequency
Easy Integration: Supports Modbus RTU protocol; seamless integration with existing industrial control systems; buffer sensor signals provided for external analysis
Industrial Durability: Rugged construction with strong EMI resistance; suitable for harsh industrial environments such as power plants and oil and gas facilities
Certifications: Complies with CE, ATEX/IECEx (explosion-proof optional), and API 670 standards; meets global industrial safety and quality requirements
