ABB UFC762AE101 (a multi-spectrum flame detection module) and 3BHE006412R0101 (an industrial power supply & signal conversion module) are key components for industrial boiler combustion control systems, supporting mainstream industrial communication protocols and compatible with ABB DCS.
Technical Parameters of ABB UFC762AE101, 3BHE006412R0101
Brand: ABB
Product Series: UFC Series Flame Detection Module & 3BHE Series Industrial Power/Control Module (for industrial boiler combustion control systems)
Length: 155 mm (millimeters) for UFC762AE101; 140 mm (millimeters) for 3BHE006412R0101
Width: 100 mm (millimeters) for UFC762AE101; 95 mm (millimeters) for 3BHE006412R0101
Height: 135 mm (millimeters) for UFC762AE101; 128 mm (millimeters) for 3BHE006412R0101
Installation Depth: 115 mm (millimeters) for UFC762AE101; 108 mm (millimeters) for 3BHE006412R0101 (including connector extension)
Product Models: UFC762AE101, 3BHE006412R0101
Module Type: UFC762AE101 - Multi-spectrum Flame Detection Module; 3BHE006412R0101 - Industrial Power Supply & Signal Conversion Module
Detection Spectrum (UFC762AE101): Covers UV (Ultraviolet) and IR (Infrared) spectrum, suitable for gas, oil and coal-fired burners
Signal Processing (UFC762AE101): Built-in high-speed signal processing chip, response time ≤ 5 ms
Conversion Accuracy (3BHE006412R0101): Analog signal conversion accuracy ±0.1%, digital signal transmission error rate < 10⁻⁶
Communication Protocol: Both support Modbus RTU, HART, and Profinet industrial communication protocols
Compatibility: Suitable for ABB Symphony Plus, Advant OCS and other distributed control systems (DCS)
Programming & Configuration Software: Supported by ABB Control Builder M and HMI Control Panel
Net Weight: 520 g (grams) for UFC762AE101; 480 g (grams) for 3BHE006412R0101
Gross Weight (including packaging): 680 g (grams) for UFC762AE101; 630 g (grams) for 3BHE006412R0101
Operating Temperature Range: -30°C to +70°C (no condensation) for both models
Storage Temperature Range: -40°C to +85°C for both models
Operating Humidity Range: 5% to 95% relative humidity (no condensation) for both models
Temperature Resistance Standard: Both comply with IEC 60068-2-1 (low temperature) and IEC 60068-2-2 (high temperature) standard
Power Input Type: DC (Direct Current) input for both models
Rated Input Voltage: 24V DC (allowable fluctuation range: 18V DC to 32V DC) for both models
Input Current: Typical operating current 0.6A, maximum inrush current 1.2A for UFC762AE101; Typical operating current 0.5A, maximum inrush current 1.0A for 3BHE006412R0101
Special Input (UFC762AE101): Flame signal input (UV/IR sensor signal), input impedance ≥ 20 kΩ
Special Input (3BHE006412R0101): Analog input (4-20 mA, 0-10 V) and digital input (dry contact), input impedance ≥ 10 kΩ
Wiring Method: Screw terminal wiring, supporting shielded cable connection for anti-interference (both models)
