3BSE011180R1 is a high-performance industrial control module developed by ABB, specifically designed for use in distributed control systems (DCS). It is engineered to meet the rigorous requirements of industrial automation environments, providing reliable and stable signal processing and control capabilities to ensure the smooth operation of complex industrial processes.
UFC719AE101 1 Basic Information (Brand & Model) Brand: ABB Model: UFC719AE101 Product Category: Industrial Control Accessory/Module 2 Physical Parameters (Weight & Dimensions) Weight: Approx. 0.85 kg (subject to actual product) Dimensions (Length × Width × Height): 120 mm × 80 mm × 45 mm (standard installation size, compatible with ABB standard control cabinets) 3 Electrical Parameters Operating Voltage: DC 24 V ± 10% Operating Current: ≤ 1.5 A Input Signal Type: Digital Input (DI), 24 VDC Output Signal Type: Relay Output, Contact Rating: AC 250 V / 5 A, DC 30 V / 5 A 4 Environmental Parameters Operating Temperature Range: -20 °C to +60 °C Storage Temperature Range: -40 °C to +85 °C Relative Humidity: 5% to 95% (non-condensing) Vibration Resistance: 10-50 Hz, 0.5 g (rms) 5 Key Performance Parameters Response Time: ≤ 10 ms Insulation Resistance: ≥ 100 MΩ (500 VDC) Dielectric Strength: 2 kV AC, 1 minute MTBF (Mean Time Between Failures): ≥ 100,000 hours 3BHB003041R0101 1 Basic Information (Brand & Model) Brand: ABB Model: 3BHB003041R0101 Product Category: Power Supply Module for DCS 2 Physical Parameters (Weight & Dimensions) Weight: Approx. 2.2 kg (subject to actual product) Dimensions (Length × Width × Height): 180 mm × 150 mm × 110 mm (standard 3U rack-mounted design) 3 Electrical Parameters Input Voltage: AC 100-240 V ± 10%, 50/60 Hz Output Voltage: DC 24 V Output Current: 20 A Voltage Regulation: ≤ ±0.5% (full load) Ripple & Noise: ≤ 50 mVpp 4 Environmental Parameters Operating Temperature Range: 0 °C to +55 °C Storage Temperature Range: -40 °C to +85 °C Relative Humidity: 10% to 90% (non-condensing) Altitude: ≤ 2000 meters (derate 1% per 100 meters above 2000 meters) 5 Key Performance Parameters Efficiency: ≥ 90% (full load, 230 VAC input) Overload Protection: 110%-150% of rated current, auto-recovery after fault removal Overvoltage Protection: 28 VDC ± 0.5 VDC Short Circuit Protection: Current limiting, auto-recovery MTBF (Mean Time Between Failures): ≥ 150,000 hours
interface *Output method: rear output *Fast Ethernet: 3 slots, each slot supports 8 ports, with optional optical and electrical options *Gigabit Ethernet: Provides 4 1000Base SFP slots *CONSOLE port: RS232 (RJ45) *Alarm port: 5.08mm spacing 3-pin Phoenix wiring terminal, 250VAC/220VDC 2 A cable *Twisted pair cable: 100m *Multimode fiber: 1310nm, 2km (100Mbps); 1310nm, 500m (gigabit) *Single mode fiber: 1310nm, 0-40km; 1550nm, 0-80km source *Input voltage: 110-220VDC/VAC, redundant input *Connection terminal: 5.08mm spacing 5-pin Phoenix wiring terminal *Power:<40W mechanical properties *Case: Aluminum model with fanless design *Protection level: IP30 *Installation method: 19 inch 1U rack type *Shell size: 440 mm * 44.5 mm * 370 mm (W * H * D), as shown in the attached image *Impact, vibration, and drop: meet the requirements of IEC61850-3 5.5 CM level *Weight: approximately 4.3kg
