HIMA TM202-A00-B00-C00-D00-E00-G00 is a high-performancesafety-related input moduledeveloped by HIMA, a leading German provider of industrial safety automation solutions.
HIMA TM202-A00-B00-C00-D00-E00-G00 is a high-performancesafety-related input moduledeveloped by HIMA, a leading German provider of industrial safety automation solutions. It is specifically designed for safety-critical applications, playing a key role in collecting and transmitting field signals to safety controllers reliably.
Core Features
Safety Certification: Complies with international safety standards includingIEC 61508(up to SIL 3) andIEC 61511(up to SIL 3 for process industry), ensuring it meets the strict safety requirements of high-risk scenarios.
Input Specifications: Typically supports multiple digital input channels (common configurations include 8 or 16 channels). It is compatible with standard field signal types such as 24V DC, enabling direct connection to sensors, switches, and other field devices.
Redundancy & Diagnostics: Integrates comprehensive self-diagnostic functions to monitor module status in real-time, promptly detecting faults like wire breaks or short circuits. It can be configured with redundant designs to enhance system availability.
System Integration: Seamlessly interfaces with HIMA's safety controller families such asH41q/H51qandHIQuad X. It communicates via the proprietary high-speed bus of HIMA systems, ensuring fast and deterministic data transmission.
interface *Output method: rear output *Fast Ethernet: 3 slots, each slot supports 8 ports, with optional optical and electrical options *Gigabit Ethernet: Provides 4 1000Base SFP slots *CONSOLE port: RS232 (RJ45) *Alarm port: 5.08mm spacing 3-pin Phoenix wiring terminal, 250VAC/220VDC 2 A cable *Twisted pair cable: 100m *Multimode fiber: 1310nm, 2km (100Mbps); 1310nm, 500m (gigabit) *Single mode fiber: 1310nm, 0-40km; 1550nm, 0-80km source *Input voltage: 110-220VDC/VAC, redundant input *Connection terminal: 5.08mm spacing 5-pin Phoenix wiring terminal *Power:<40W mechanical properties *Case: Aluminum model with fanless design *Protection level: IP30 *Installation method: 19 inch 1U rack type *Shell size: 440 mm * 44.5 mm * 370 mm (W * H * D), as shown in the attached image *Impact, vibration, and drop: meet the requirements of IEC61850-3 5.5 CM level *Weight: approximately 4.3kg
