TK-FXX102 Honeywell DCS Chassis & Integrated Backplane

TK-FXX102 DCS Chassis & Integrated Backplane
Brand: Honeywell
Model: TK-FXX102
Order Part Number: TK-FXX102 (Alternative PN:97126875-A01)
Product Name: 10-Slot Series C DCS Chassis & Integrated Backplane
Origin: United States
HS Code: 8538909000
Dimension: 400mm × 172mm × 145mm

Net Weight: 1.40kg
Input
External main power input: 24VDC ±10% industrial DC power access for chassis power conversion.
Output
Internal multi-channel regulated power output:5.1VDC(15/6A),3.3VDC(4/4A),24VDC(2.8/2.8A) to each slot backplane; high-speed parallel bus signal output for inter-module data transmission.

interface
*Output method: rear output
*Fast Ethernet: 3 slots, each slot supports 8 ports, with optional optical and electrical options
*Gigabit Ethernet: Provides 4 1000Base SFP slots
*CONSOLE port: RS232 (RJ45)
*Alarm port: 5.08mm spacing 3-pin Phoenix wiring terminal, 250VAC/220VDC 2 A
cable
*Twisted pair cable: 100m
*Multimode fiber: 1310nm, 2km (100Mbps); 1310nm, 500m (gigabit)
*Single mode fiber: 1310nm, 0-40km; 1550nm, 0-80km
source
*Input voltage: 110-220VDC/VAC, redundant input
*Connection terminal: 5.08mm spacing 5-pin Phoenix wiring terminal
*Power:<40W
mechanical properties
*Case: Aluminum model with fanless design
*Protection level: IP30
*Installation method: 19 inch 1U rack type
*Shell size: 440 mm * 44.5 mm * 370 mm (W * H * D), as shown in the attached image
*Impact, vibration, and drop: meet the requirements of IEC61850-3 5.5 CM level
*Weight: approximately 4.3kg

*10 Mbps forwarding speed: 14881pps
*100Mbps forwarding speed: 148810pps
*Transmission method: storage and forwarding
*System exchange bandwidth: 1.6Gbps
*Cache size: 1Mbits
*MAC address table: 2K
