RH102AN Foxboro Switch

Foxboro RH102AN Specification
Widely deployed in power plant, petrochemical, oil & gas, pulp & paper and water treatment automatic control sites to realize stable data interconnection between DCS controllers, field I/O modules and upper monitoring host. Its cast aluminum shell resists dust, vibration and electromagnetic interference, adapting to -40℃~+75℃ wide temperature industrial cabinet environment.

Brand: Foxboro
Model: RH102AN
Order Part Number: RH102AN (Alias: X440-G2-24FX-GE4)
Product Name: Industrial Managed Mesh Ethernet Switch
Origin: United States
HS Code: 8517629000
Dimension: 445mm × 133mm × 45mm (19-inch rack standard size)
Net Weight: 2.04kg (4.5lbs)
Electrical Input & Output
Input
1. Power Input: DC24V rated working power, allowable input range 18~30VDC, dual redundant power terminal access for backup power connection;
2. Signal Input: 24-channel 100Base-FX LC fiber signal input, 4 vacant 1000Base-X SFP slot input for optional gigabit module access; 1×RJ45 serial console port for local debugging signal input.
Output
1. Network Output: 24-channel fiber Ethernet signal output, 4-channel SFP gigabit uplink signal output; 1×10/100/1000BASE-T RJ45 management port output for upper network access;

2. Auxiliary Output: LED indicator signal output for power status, port link and network fault alarm display.

interface
*Output method: rear output
*Fast Ethernet: 3 slots, each slot supports 8 ports, with optional optical and electrical options
*Gigabit Ethernet: Provides 4 1000Base SFP slots
*CONSOLE port: RS232 (RJ45)
*Alarm port: 5.08mm spacing 3-pin Phoenix wiring terminal, 250VAC/220VDC 2 A
cable
*Twisted pair cable: 100m
*Multimode fiber: 1310nm, 2km (100Mbps); 1310nm, 500m (gigabit)
*Single mode fiber: 1310nm, 0-40km; 1550nm, 0-80km
source
*Input voltage: 110-220VDC/VAC, redundant input
*Connection terminal: 5.08mm spacing 5-pin Phoenix wiring terminal
*Power:<40W
mechanical properties
*Case: Aluminum model with fanless design
*Protection level: IP30
*Installation method: 19 inch 1U rack type
*Shell size: 440 mm * 44.5 mm * 370 mm (W * H * D), as shown in the attached image
*Impact, vibration, and drop: meet the requirements of IEC61850-3 5.5 CM level
*Weight: approximately 4.3kg

*10 Mbps forwarding speed: 14881pps
*100Mbps forwarding speed: 148810pps
*Transmission method: storage and forwarding
*System exchange bandwidth: 1.6Gbps
*Cache size: 1Mbits
*MAC address table: 2K
