Rexroth PPC-R02.2N-N-Q1-P2-NN-FW R911288408 processor module

Rexroth PPC-R02.2N-N-Q1-P2-NN-FW (R911288408) Technical Description & Specifications
Core Identification Information
Brand: Bosch Rexroth;
Model: PPC-R02.2N-N-Q1-P2-NN-FW;
Order Part Number: R911288408;
Product Name: Motion Control Processor Module;
Country of Origin: Germany;
HS Code (Harmonized System Code): 85371090;
Physical Specifications
Dimensions: 156 mm × 101 mm × 46 mm;
Weight: 0.73 kg;
Electrical Specifications
Input: Encoder feedback input, digital command input;
Output: Analog control output, digital drive signal output;
Power Supply: 24 V DC (18–30 V DC) operating voltage;

Product Characteristics
High-speed multi-axis synchronous motion control capability;
High-precision closed-loop positioning and motion algorithm;
Supports EtherCAT, SERCOS and other high-speed fieldbus protocols;
Integrated motion programming and built-in diagnostic functions;
High anti-interference performance for industrial automation environments;
DIN-rail mounting design for standard cabinet installation;
Fully compatible with Rexroth drive and control system ecosystem.

interface
*Output method: rear output
*Fast Ethernet: 3 slots, each slot supports 8 ports, with optional optical and electrical options
*Gigabit Ethernet: Provides 4 1000Base SFP slots
*CONSOLE port: RS232 (RJ45)
*Alarm port: 5.08mm spacing 3-pin Phoenix wiring terminal, 250VAC/220VDC 2 A
cable
*Twisted pair cable: 100m
*Multimode fiber: 1310nm, 2km (100Mbps); 1310nm, 500m (gigabit)
*Single mode fiber: 1310nm, 0-40km; 1550nm, 0-80km
source
*Input voltage: 110-220VDC/VAC, redundant input
*Connection terminal: 5.08mm spacing 5-pin Phoenix wiring terminal
*Power:<40W
mechanical properties
*Case: Aluminum model with fanless design
*Protection level: IP30
*Installation method: 19 inch 1U rack type
*Shell size: 440 mm * 44.5 mm * 370 mm (W * H * D), as shown in the attached image
*Impact, vibration, and drop: meet the requirements of IEC61850-3 5.5 CM level
*Weight: approximately 4.3kg

*10 Mbps forwarding speed: 14881pps
*100Mbps forwarding speed: 148810pps
*Transmission method: storage and forwarding
*System exchange bandwidth: 1.6Gbps
*Cache size: 1Mbits
*MAC address table: 2K
