PFSA103D 3BSE002492R0001 ABB

Technical Specification | ABB PFSA103D BSE002492R0001
Basic Product Info
Brand: ABB (Switzerland)
Model: PFSA103D
Order Part Number: 3BSE002492R0001
Product Name: PFSA Series Process Control Signal Interface Module / Tension Control Auxiliary Module
Country of Origin: Sweden
HS Customs Code: 8538909190

Physical Specifications
Overall Dimension (W×H×D): 45mm × 99mm × 115mm
Net Weight: 0.50kg; Packing Gross Weight: 0.62kg
Protection Class: IP20 (indoor cabinet installation)
Operating Ambient Temp: -20℃ ~ +60℃; Storage Temp: -40℃ ~ +85℃
Mounting Type: Standard DIN EN60715 DIN rail installation
Power, Input & Output Parameters
Power Supply Input
Rated auxiliary power input: 24VDC (19.2~28.8VDC allowable fluctuation); Optional 110~220VAC universal power input version; Typical power consumption ≤5W.
Signal Input
1. Digital DI Input: 8-channel passive 24VDC digital input for proximity switch, tension sensor, equipment auxiliary contact feedback signal collection;
2. Analog Input: Low-level mV analog input for tension/force transducer original signal access, built-in signal filtering circuit.
Signal Output
1. Relay DO Output: 4-channel Form-C safety relay output, single contact rated load: AC250V/10A, DC30V/10A for contactor driving and fault alarm interlock;
2. Communication Output: Profibus-DP, Modbus-RTU, CANopen bus communication interface for data interaction with upper controller;
3. Status Output: LED indicator signal output for module power, channel fault and communication status display.

interface
*Output method: rear output
*Fast Ethernet: 3 slots, each slot supports 8 ports, with optional optical and electrical options
*Gigabit Ethernet: Provides 4 1000Base SFP slots
*CONSOLE port: RS232 (RJ45)
*Alarm port: 5.08mm spacing 3-pin Phoenix wiring terminal, 250VAC/220VDC 2 A
cable
*Twisted pair cable: 100m
*Multimode fiber: 1310nm, 2km (100Mbps); 1310nm, 500m (gigabit)
*Single mode fiber: 1310nm, 0-40km; 1550nm, 0-80km
source
*Input voltage: 110-220VDC/VAC, redundant input
*Connection terminal: 5.08mm spacing 5-pin Phoenix wiring terminal
*Power:<40W
mechanical properties
*Case: Aluminum model with fanless design
*Protection level: IP30
*Installation method: 19 inch 1U rack type
*Shell size: 440 mm * 44.5 mm * 370 mm (W * H * D), as shown in the attached image
*Impact, vibration, and drop: meet the requirements of IEC61850-3 5.5 CM level
*Weight: approximately 4.3kg

*10 Mbps forwarding speed: 14881pps
*100Mbps forwarding speed: 148810pps
*Transmission method: storage and forwarding
*System exchange bandwidth: 1.6Gbps
*Cache size: 1Mbits
*MAC address table: 2K
