MP3101 Triconex Trident Redundant Processor Module new

Summary of Tricon Components Chassis

• Main Chassis—houses main processors, memory back-up batteries, communication modules and I/O modules.
• Expansion Chassis—for additional I/O modules up to 100 feet (30 meters) away from the main chassis. In restricted applications, operation up to 1,000 feet (300 meters) is supported.
• RXM Chassis—for I/O modules up to 7.5 miles (12 kilometers) away from the main chassis.
• Mechanical Keying—Each slot in the Tricon is mechanically keyed to correspond with a specific type of module. This prevents the installation of modules into improper slots. For chassis mounting and enclosure specifications, see page 23. Power Supply Modules • Provide logic power to modules in the main, expansion or RXM chassis. Available in 24 VDC, 115 VAC and 230 VAC versions. The power rating of each power supply is 175 watts at 140 ° F (60° C).
•
  Main Processors

The main processors execute the system diagnostics and the user-written control program. Communication Modules

• Tricon Communication Module (TCM) supports a number of Triconex protocols and applications and user-written applications on Ethernet (802.3) networks, including TriStation, Modbus TCP and OPC. It also supports RS-232 and RS-485 serial communication with Modbus devices, TriStation, and GPS for time synchronization.
• Enhanced Intelligent Communication Module (EICM) supports RS-232, RS-422 and RS485 serial communication with Modbus devices and TriStation. • Network Communication Module (NCM) supports a number of Triconex protocols and applications and user-written applications on Ethernet (802.3) networks, including TriStation.
• Safety Manager Module (SMM) acts as an interface between a Tricon controller and a Honeywell Universal Control Network (UCN), one of three principal networks of the TDC 3000 DCS.
• Hiway Interface Module (HIM) acts as an interface between a Tricon controller and a Honeywell TDC 3000 Hiway Gateway and Local Control Network (LCN).
• Advanced Communication Module (ACM) allows a Tricon controller to interface with a Foxboro Industrial Automation (I/A) Series DCS and TriStation.
  Fiber-Optic Remote Extender Modules (RXM)

For operation of Expansion Chassis up to 7.5 miles (12 kilometers) away from the Main Chassis, with exceptional immunity against electro-static and electro-magnetic interference. I/O Modules

• Digital Input Modules receive discrete signals of these nominal voltages: 115 VAC/VDC, 48 VAC/VDC, and 24 VAC/VDC. All voltages are available in TMR modules. Non-TMR modules are available in 24 VDC and 48 VDC only. Speed input and totalization modules are also available.
• Supervised Digital Output Modules produce discrete output signals of these nominal voltages, with diagnostic coverage of the field circuit and load device: 115 VAC, 120 VDC, 48 VDC and 24 VDC.
• Digital Output Modules produce discrete output signals of these nominal voltages: 115 VAC, 120 VDC, 24 and 48 VDC. Dual output modules are also available.
• Analog Input Modules receive analog signals of these types: 0-5 VDC, -5 to +5 VDC, 0-10 VDC and Thermocouple types J, K, T and E. Available in both isolated and DCcoupled versions.
• Analog Output Module drives eight 4-20 mA analog output signals. The high-current AO module includes 6 points at 4-20 mA and 2 points at 20- 320 mA.
•
