MOTOROLA MVME7100 Industrial Control Module

No.941806
Engineered for industrial control applications, the MOTOROLA MVME7100 module delivers unparalleled reliability and performance.
  • MOTOROLA MVME7100 Industrial Control Module
  • MOTOROLA MVME7100 Industrial Control Module
  • MOTOROLA MVME7100 Industrial Control Module
  • MOTOROLA MVME7100 Industrial Control Module
  • Description

  • Here's how it works

  • SPECIFICATION

Operating Voltage:12VDC

Output Frequency:10kHz

Certified Product:Yes

Series:MVME7100 Series

Material Coding:Unique

Custom Processing:Available

Place of Origin:Manufactured in Motorola's state-of-the-art facility

    The MOTOROLA MVME7100 is designed to meet the stringent demands of industrial automation environments. Its robust construction ensures longevity and reliability in harsh conditions.

    Featuring advanced signal processing capabilities, this module offers exceptional precision and speed, making it ideal for complex control systems where accuracy is paramount.

    With its versatile customization options, the MVME7100 allows engineers to tailor the module to specific application needs, enhancing system flexibility and efficiency.

    Crafted from high-grade materials, the MVME7100 boasts superior thermal management, ensuring optimal performance even under intense operational loads.

    Integrating seamlessly into existing systems, the module supports various connectivity standards, facilitating easy integration and maintenance.

MOTOROLA MVME7100

MOTOROLA MVME7100

interface
*Output method: rear output
*Fast Ethernet: 3 slots, each slot supports 8 ports, with optional optical and electrical options
*Gigabit Ethernet: Provides 4 1000Base SFP slots
*CONSOLE port: RS232 (RJ45)
*Alarm port: 5.08mm spacing 3-pin Phoenix wiring terminal, 250VAC/220VDC 2 A
cable
*Twisted pair cable: 100m
*Multimode fiber: 1310nm, 2km (100Mbps); 1310nm, 500m (gigabit)
*Single mode fiber: 1310nm, 0-40km; 1550nm, 0-80km
source
*Input voltage: 110-220VDC/VAC, redundant input
*Connection terminal: 5.08mm spacing 5-pin Phoenix wiring terminal
*Power:<40W
mechanical properties
*Case: Aluminum model with fanless design
*Protection level: IP30
*Installation method: 19 inch 1U rack type
*Shell size: 440 mm * 44.5 mm * 370 mm (W * H * D), as shown in the attached image
*Impact, vibration, and drop: meet the requirements of IEC61850-3 5.5 CM level
*Weight: approximately 4.3kg
*10 Mbps forwarding speed: 14881pps
*100Mbps forwarding speed: 148810pps
*Transmission method: storage and forwarding
*System exchange bandwidth: 1.6Gbps
*Cache size: 1Mbits
*MAC address table: 2K
