MOTOROLA CPCI-6020TM: Advanced Communication Module for Industrial Automation

No.941744
Engineered for seamless integration in industrial automation systems, the MOTOROLA CPCI-6020TM is a high-performance communication module designed to enhance system reliability and efficiency.
  • MOTOROLA CPCI-6020TM: Advanced Communication Module for Industrial Automation
  • MOTOROLA CPCI-6020TM: Advanced Communication Module for Industrial Automation
  • MOTOROLA CPCI-6020TM: Advanced Communication Module for Industrial Automation
  • MOTOROLA CPCI-6020TM: Advanced Communication Module for Industrial Automation
  • Description

  • Here's how it works

  • SPECIFICATION

Operating Voltage:220 V

Certified Product:Yes

Custom Processing:Yes

Model:CPCI-6020TM

Brand:MOTOROLA

Item No.:CPCI-6020TM

Module Type:CompactPCI

Series:MOTOROLA

Material Number:CPCI-6020TM

    The MOTOROLA CPCI-6020TM is specifically engineered to withstand the rigors of industrial environments, ensuring robust performance under extreme conditions.

    Featuring advanced communication protocols, this module ensures reliable data transfer, making it an indispensable part of complex automation systems.

    With its compact design, the CPCI-6020TM seamlessly integrates into existing systems without requiring significant modifications, facilitating quick deployment.

    Utilizing state-of-the-art materials, the module is built for longevity and durability, offering exceptional value for industrial applications.

    Ease of use is paramount, with straightforward installation procedures and comprehensive documentation, ensuring minimal downtime during maintenance or upgrades.

MOTOROLA CPCI-6020TM

MOTOROLA CPCI-6020TM

interface
*Output method: rear output
*Fast Ethernet: 3 slots, each slot supports 8 ports, with optional optical and electrical options
*Gigabit Ethernet: Provides 4 1000Base SFP slots
*CONSOLE port: RS232 (RJ45)
*Alarm port: 5.08mm spacing 3-pin Phoenix wiring terminal, 250VAC/220VDC 2 A
cable
*Twisted pair cable: 100m
*Multimode fiber: 1310nm, 2km (100Mbps); 1310nm, 500m (gigabit)
*Single mode fiber: 1310nm, 0-40km; 1550nm, 0-80km
source
*Input voltage: 110-220VDC/VAC, redundant input
*Connection terminal: 5.08mm spacing 5-pin Phoenix wiring terminal
*Power:<40W
mechanical properties
*Case: Aluminum model with fanless design
*Protection level: IP30
*Installation method: 19 inch 1U rack type
*Shell size: 440 mm * 44.5 mm * 370 mm (W * H * D), as shown in the attached image
*Impact, vibration, and drop: meet the requirements of IEC61850-3 5.5 CM level
*Weight: approximately 4.3kg
*10 Mbps forwarding speed: 14881pps
*100Mbps forwarding speed: 148810pps
*Transmission method: storage and forwarding
*System exchange bandwidth: 1.6Gbps
*Cache size: 1Mbits
*MAC address table: 2K
