The MIFHIPI55E10HI00 is a rugged, high-efficiency industrial inverter from GE’s advanced drive lineup, engineered for precise motor speed control and energy optimization in heavy-duty industrial applications.
MIFHIPI55E10HI00 GE Core Electrical Specifications
Input Voltage: Three-phase AC 380–480 V (±10% tolerance)
Input Frequency: 50/60 Hz (±5% tolerance)
Output Voltage: Three-phase AC 0–input voltage (adjustable)
Output Frequency Range: 0.1–500 Hz (precision ±0.01 Hz)
Rated Power: 55 kW (75 HP) at 40 °C ambient temperature
Output Current: 110 A (continuous), 150% overload for 60 seconds
Efficiency: ≥97.5% (at rated load, 480 V input, 50 Hz output)
Control Mode: V/F (Voltage/Frequency) control, Vector control (sensorless), Closed-loop vector control (with optional encoder feedback)
Starting Torque: ≥150% at 0.5 Hz (sensorless vector mode); ≥200% at 0 Hz (closed-loop vector mode)
Power Factor: ≥0.95 (at rated load)
MIFHIPI55E10HI00 GE Physical Characteristics
Dimensions (W × H × D): 450 mm × 760 mm × 320 mm (17.72 in × 29.92 in × 12.60 in) – including cooling fan and terminal cover
Net Weight: 38 kg (83.78 lbs)
Mounting Type: Wall-mounted (vertical) or cabinet-integrated (with proper ventilation)
Enclosure Material: Powder-coated steel (corrosion-resistant)
Ingress Protection Rating: IP21 (standard); optional IP54 rating with protective cover kit
MIFHIPI55E10HI00 GE Environmental Parameters
Operating Temperature: –10 °C to +50 °C (14 °F to 122 °F) – derate 1% per °C above 40 °C
Storage Temperature: –25 °C to +70 °C (–13 °F to 158 °F)
Relative Humidity: 5%–95% non-condensing (no dew formation)
Altitude: Up to 1,000 m (3,280 ft) without derating; derate 5% per 1,000 m above 1,000 m (maximum 4,000 m)
Vibration Resistance: 5.9 m/s² (0.6 Grms) at 10–500 Hz (operating); 15.7 m/s² (1.6 Grms) at 10–500 Hz (storage)
Shock Resistance: 39.2 m/s² (4 G) for 11 ms (operating); 78.5 m/s² (8 G) for 11 ms (storage)
Cooling Method: Forced air cooling (variable-speed fan with temperature-based speed control)
MIFHIPI55E10HI00 GE Performance & Functional Features
Digital Display: Integrated LCD keypad with multi-language support (English, German, French, Spanish, Chinese) for parameter configuration and real-time monitoring
Communication Interfaces: Standard RS485 (Modbus RTU); optional Ethernet (Modbus TCP/IP, PROFINET, EtherNet/IP)
Protection Functions: Overcurrent, overvoltage, undervoltage, overheating, short circuit, phase loss (input/output), motor overload, ground fault, and external fault protection
Configurable Parameters: Acceleration/deceleration time (0.1–3600 seconds), V/F curve customization, torque limit, speed limit, PID control (for process regulation), and automatic energy-saving mode
Auxiliary Outputs: 2 × relay outputs (Form-C, 5 A @ 250 Vac / 30 Vdc) for alarm and interlock signals; 1 × analog output (4–20 mA / 0–10 Vdc) for speed or current feedback
MIFHIPI55E10HI00 GE Safety & Compliance
Certifications: CE, UL, cUL, RoHS compliant
Insulation Class: Class F (155 °C)
Overvoltage Category: III
Pollution Degree: 2 (per IEC 664)
