KYMA KDU-200.1 DCS Monitoring Display Unit

KYMA KDU-200.1
Brand: KYMA
Model: KDU-200.1
Order Number: KDU-200.1
Product Name: Marine Performance Monitoring Display Unit
Place of Origin: Taiwan
Customs Code: HS 85371090
Dimensions: 220 mm × 160 mm × 50 mm
Weight: 1.8 kg (net)

Temperature: Operating -15°C to +60°C; Storage -30°C to +70°C
Electrical: Supply 12 VDC (6.67 A); 7" wide-screen LCD; Touchscreen; Ethernet, CAN bus, NMEA 2000; Isolation 2.5 kV AC; IP65 front
Key Features: Windows Embedded OS; High-brightness display; Marine navigation data integration; Vessel performance analytics; DNV/GL type approved

Application Cases:
1. Ship Bridge Monitoring: Navigation and performance display on commercial vessel bridges, showing speed, fuel consumption, and route data.
2. Dynamic Positioning (DP): Provides position and thruster status feedback for offshore vessel DP systems.
3. Fishing Vessel Systems: Displays catch data, tank levels, and navigation for commercial fishing boats.

interface
*Output method: rear output
*Fast Ethernet: 3 slots, each slot supports 8 ports, with optional optical and electrical options
*Gigabit Ethernet: Provides 4 1000Base SFP slots
*CONSOLE port: RS232 (RJ45)
*Alarm port: 5.08mm spacing 3-pin Phoenix wiring terminal, 250VAC/220VDC 2 A
cable
*Twisted pair cable: 100m
*Multimode fiber: 1310nm, 2km (100Mbps); 1310nm, 500m (gigabit)
*Single mode fiber: 1310nm, 0-40km; 1550nm, 0-80km
source
*Input voltage: 110-220VDC/VAC, redundant input
*Connection terminal: 5.08mm spacing 5-pin Phoenix wiring terminal
*Power:<40W
mechanical properties
*Case: Aluminum model with fanless design
*Protection level: IP30
*Installation method: 19 inch 1U rack type
*Shell size: 440 mm * 44.5 mm * 370 mm (W * H * D), as shown in the attached image
*Impact, vibration, and drop: meet the requirements of IEC61850-3 5.5 CM level
*Weight: approximately 4.3kg

*10 Mbps forwarding speed: 14881pps
*100Mbps forwarding speed: 148810pps
*Transmission method: storage and forwarding
*System exchange bandwidth: 1.6Gbps
*Cache size: 1Mbits
*MAC address table: 2K
