IS420UCECH1B-E GE CPU controller

IS420UCECH1B-E  Basic Info
Brand: General Electric (GE)
Model No.: IS420UCECH1B-E
Order Code: IS420UCECH1B-E
Product Name: Mark VIe UCEC Main Central Controller Module
Country of Origin: USA
HS Code:8538909100
Dimension:178mm(H)×127mm(W)×76mm(D)
Net Weight:0.82kg
Input Parameter
1. Power Input: DC24V rated working power input, working current 0.3~1.1A
2. Communication Input: Multi-channel HSSL high-speed serial bus input, Ethernet/IONet/RS485 communication signal input
3. Field I/O Input: Analog/digital signal access from downstream EX2100e backplane boards


1. Bus Output: HSSL expansion bus output cascading multi-group I/O card racks
2. Network Output: Dual Ethernet port for upper DCS system data upload
3. Status Output: LED indicator output for power, communication and fault diagnosis
Working Temp:-40℃~+70℃, non-condensing humidity 5%~95%

interface
*Output method: rear output
*Fast Ethernet: 3 slots, each slot supports 8 ports, with optional optical and electrical options
*Gigabit Ethernet: Provides 4 1000Base SFP slots
*CONSOLE port: RS232 (RJ45)
*Alarm port: 5.08mm spacing 3-pin Phoenix wiring terminal, 250VAC/220VDC 2 A
cable
*Twisted pair cable: 100m
*Multimode fiber: 1310nm, 2km (100Mbps); 1310nm, 500m (gigabit)
*Single mode fiber: 1310nm, 0-40km; 1550nm, 0-80km
source
*Input voltage: 110-220VDC/VAC, redundant input
*Connection terminal: 5.08mm spacing 5-pin Phoenix wiring terminal
*Power:<40W
mechanical properties
*Case: Aluminum model with fanless design
*Protection level: IP30
*Installation method: 19 inch 1U rack type
*Shell size: 440 mm * 44.5 mm * 370 mm (W * H * D), as shown in the attached image
*Impact, vibration, and drop: meet the requirements of IEC61850-3 5.5 CM level
*Weight: approximately 4.3kg

*10 Mbps forwarding speed: 14881pps
*100Mbps forwarding speed: 148810pps
*Transmission method: storage and forwarding
*System exchange bandwidth: 1.6Gbps
*Cache size: 1Mbits
*MAC address table: 2K
