GE IS220UCSAH1A Technical Specifications
General Information
Brand: GE
Model: IS220UCSAH1A
Product Category: Industrial Automation Control Module (Analog Input/Output Module)
Dimensions
Length: 6.5 inches (165.1 mm)
Width: 3.8 inches (96.52 mm)
Height: 2.2 inches (55.88 mm)
Mounting Type: DIN Rail or Panel Mount
Core Specifications
Signal Resolution: 16-bit
Sampling Rate: Up to 100 Hz per channel
Isolation: Channel-to-Channel Electrical Isolation (2500 VAC)
Power Supply Requirement: 24 VDC ±10% (1.2 A Max)
Weight
Net Weight: 0.85 lbs (0.385 kg)
Gross Weight (with Packaging): 1.2 lbs (0.544 kg)
Input Parameters
Input Type: Analog Input (Configurable)
Input Channels: 8 Differential Channels
Input Ranges: Support for 4-20 mA (current), 0-10 VDC (voltage), ±5 VDC (voltage)
Input Impedance: 100 Ω (for current inputs), 100 kΩ (for voltage inputs)
Overload Protection: ±30 VDC (voltage inputs), 30 mA (current inputs)
Output Parameters
Output Type: Analog Output (Configurable)
Output Channels: 4 Channels
Output Ranges: 4-20 mA (current), 0-10 VDC (voltage)
Output Accuracy: ±0.1% of Full Scale (at 25°C)
Load Capacity: Max 500 Ω (for current outputs), Min 1 kΩ (for voltage outputs)
Short-Circuit Protection: Built-in Short-Circuit Detection and Auto-Recovery
Operating Temperature Range
Operating Temperature: -40°C to 70°C (-40°F to 158°F)
Storage Temperature: -40°C to 85°C (-40°F to 185°F)
Humidity Range: 5% to 95% RH (Non-Condensing)
