The GE IS220PDOAH1A Discrete Output Pack is primarily used in industrial automation and turbine control systems, specifically within GE's Speedtronic Mark VI platform. It excels in applications such as gas turbine control, steam turbine control, power generation facilities, oil and gas refineries, chemical processing plants, and other heavy industrial environments requiring precise and reliable discrete output control.
GE IS220PDOAH1A Technical Specifications Brand & Model Brand: GE Boards & Turbine Control (General Electric) Model: IS220PDOAH1A Series: Mark VI IS200 Product Type: Discrete Output Pack (PDOA) specifically designed for GE's Speedtronic Mark VI turbine control system, providing an electrical interface between one or two I/O Ethernet networks and discrete output terminal boards for industrial automation applications requiring reliable on/off switching contro Physical Dimensions & Weight Dimensions (H×W×D): 3.25" (82.55 mm) high × 1.65" (41.91 mm) wide × 4.78" (121.41 mm) deep Net Weight: Approximately 0.5 kg (1 lb) for easy handling and installation in control cabinets Mounting: Designed for integration with Mark VI control system racks, compatible with standard industrial cabinet mounting configurations Housing: Rugged industrial-grade enclosure with flame-retardant properties, built to withstand harsh industrial environments Protection Rating: IP20 front panel protection against dust and solid objects; compliant with industrial safety standards for electrical equipment Core Technical Parameters Output Channels: 12 discrete relay output channels for versatile application support Compatible Terminal Boards: Works with six discrete output terminal boards, including SRLY and TRLY models Connectors: 3 total - 1 DC power connector and 2 RJ45 Ethernet connectors for network communication LED Indicators: Four LEDs for system status monitoring - Power (indicates module power), Attention (alerts to potential issues), TxRx (transmit/receive activity), and Link (network connection status) Power Input: 28 V DC power supply for reliable operation in industrial control systems Operating Temperature: -30°C to +65°C (-22°F to +149°F) for operation in extreme industrial environments Storage Temperature: -40°C to +85°C (-40°F to +185°F) for extended environmental tolerance Relative Humidity: 5% to 95% non-condensing for reliable performance in varying humidity conditions Vibration Resistance: 5g RMS for durability in high-vibration industrial settings Isolation: Optical isolation for enhanced noise immunity and protection against electrical surges Key Product Features 12 Discrete Output Channels: Provides versatile on/off switching capabilities for controlling various industrial devices, including valves, motors, and actuators Dual Ethernet Connectivity: Two RJ45 Ethernet ports support up to two I/O Ethernet networks, enabling redundant communication paths for enhanced system reliability LED Status Monitoring: Four dedicated LEDs offer real-time system status visibility, simplifying troubleshooting and maintenance procedures Wide Compatibility: Works seamlessly with multiple discrete output terminal boards (SRLY, TRLY, etc.), providing flexibility in system configuration Robust Industrial Design: Built to withstand harsh industrial environments with wide temperature range, vibration resistance, and optical isolation for noise immunity Easy Integration: Designed specifically for Mark VI IS200 series systems, ensuring plug-and-play compatibility and reducing installation time Surface Mount Technology: Utilizes advanced surface mount components for improved reliability and space efficiency Safety Compliance: Meets global industrial safety standards for electrical equipment, ensuring safe operation in industrial automation applications
interface *Output method: rear output *Fast Ethernet: 3 slots, each slot supports 8 ports, with optional optical and electrical options *Gigabit Ethernet: Provides 4 1000Base SFP slots *CONSOLE port: RS232 (RJ45) *Alarm port: 5.08mm spacing 3-pin Phoenix wiring terminal, 250VAC/220VDC 2 A cable *Twisted pair cable: 100m *Multimode fiber: 1310nm, 2km (100Mbps); 1310nm, 500m (gigabit) *Single mode fiber: 1310nm, 0-40km; 1550nm, 0-80km source *Input voltage: 110-220VDC/VAC, redundant input *Connection terminal: 5.08mm spacing 5-pin Phoenix wiring terminal *Power:<40W mechanical properties *Case: Aluminum model with fanless design *Protection level: IP30 *Installation method: 19 inch 1U rack type *Shell size: 440 mm * 44.5 mm * 370 mm (W * H * D), as shown in the attached image *Impact, vibration, and drop: meet the requirements of IEC61850-3 5.5 CM level *Weight: approximately 4.3kg
