IS215WEPAH2A GE

IS215WEPAH2A Basic Information
Brand: General Electric (GE)
Model No.:IS215WEPAH2A
Order Code:IS215WEPAH2A
Product Name: WEPA High Precision Analog Acquisition Main Board
Country of Origin: United States
HS Code:8538909100

Dimension:252mm×153mm×34mm
Net Weight:1.27kg
Input Parameters
1. Analog Signal Input: Preprocessed analog signal from IS210AEAAH2B terminal base board
2. Working Power Input: Dual redundant 24VDC input
3. HSSL Bus Input: Synchronous control command from rack central controller
Output Parameters
1. Digital Sampling Output: Converted digital sampled data via backplane bus to UCEC main controller
2. Channel Fault Alarm Output: Overrange/open-circuit fault passive contact output
3. Debug Communication Output: Local RS232 debug interface output for on-site calibration
Working Temp:-40℃~+72℃

interface
*Output method: rear output
*Fast Ethernet: 3 slots, each slot supports 8 ports, with optional optical and electrical options
*Gigabit Ethernet: Provides 4 1000Base SFP slots
*CONSOLE port: RS232 (RJ45)
*Alarm port: 5.08mm spacing 3-pin Phoenix wiring terminal, 250VAC/220VDC 2 A
cable
*Twisted pair cable: 100m
*Multimode fiber: 1310nm, 2km (100Mbps); 1310nm, 500m (gigabit)
*Single mode fiber: 1310nm, 0-40km; 1550nm, 0-80km
source
*Input voltage: 110-220VDC/VAC, redundant input
*Connection terminal: 5.08mm spacing 5-pin Phoenix wiring terminal
*Power:<40W
mechanical properties
*Case: Aluminum model with fanless design
*Protection level: IP30
*Installation method: 19 inch 1U rack type
*Shell size: 440 mm * 44.5 mm * 370 mm (W * H * D), as shown in the attached image
*Impact, vibration, and drop: meet the requirements of IEC61850-3 5.5 CM level
*Weight: approximately 4.3kg

*10 Mbps forwarding speed: 14881pps
*100Mbps forwarding speed: 148810pps
*Transmission method: storage and forwarding
*System exchange bandwidth: 1.6Gbps
*Cache size: 1Mbits
*MAC address table: 2K
