IS200WNPSH1ABA MRP646180 GE Power Supply NEW IN STOCK
GE IS200WNPSH1ABA MRP646180 is manufactured by General Electric (GE) under the GE Boards & Turbine Control division, a leading provider of industrial control solutions specifically designed for the demanding requirements of turbine and power generation applications. The product is also commonly referred to as GE Fanuc IS200WNPSH1ABA in some industrial documentation.
IS200WNPSH1ABA MRP646180 - GE Mark VI Speedtronic Power Supply Daughter Card Overview The IS200WNPSH1ABA MRP646180 is a high-reliability Power Supply Daughter Card (functional acronym: WNPS) developed by GE Boards & Turbine Control for the Mark VI Speedtronic industrial turbine control system. It serves as a critical component that provides essential power distribution, monitoring, and protection functions for the control system's terminal boards and associated I/O modules, ensuring stable and safe operation of gas and steam turbine control applications in power generation, oil and gas, and other heavy industries. This daughter card is designed to work seamlessly with the Mark VI IS200 series platform, offering backward compatibility with the first two revisions of the product line for flexible system upgrades and maintenance. Technical Specifications Brand & Manufacturer The product is manufactured by General Electric (GE) under the GE Boards & Turbine Control division, a leading provider of industrial control solutions specifically designed for the demanding requirements of turbine and power generation applications. The product is also commonly referred to as GE Fanuc IS200WNPSH1ABA in some industrial documentation. Model Number The full model designation is IS200WNPSH1ABA MRP646180, where: IS200: Denotes the Mark VI IS200 product series for turbine control systems WNPS: Functional acronym for Power Supply Daughter Card H1ABA: Hardware revision and configuration code specifying the board's specific features and compatibility MRP708215: GE's internal material requirement planning (MRP) part number for inventory and procurement purposes Physical Specifications Dimensions The IS200WNPSH1ABA features a compact form factor optimized for installation within Mark VI control system cabinets, with standard dimensions of 125 mm × 125 mm × 30 mm (4.92 in × 4.92 in × 1.18 in). This space-efficient design allows for high-density mounting alongside other control modules in industrial enclosures. Weight The unit has a net weight of 350 grams (0.77 lbs) without additional accessories, facilitating easy handling during installation, replacement, and maintenance procedures in control room environments. Mounting It is designed for direct mounting onto the main power supply board or terminal system of the Mark VI Speedtronic platform, utilizing a secure screw-mounting mechanism that ensures stable electrical connections and resistance to vibration in industrial settings. Core Features Integrated Power Distribution: Provides regulated power outputs to terminal boards and I/O modules within the Mark VI control system, supporting a voltage range from +28V to -28V DC for versatile compatibility with various system components. Advanced Power Monitoring: Embedded power sensing capabilities that continuously monitor voltage and current levels, enabling early detection of power anomalies and facilitating predictive maintenance strategies. Robust Protection Mechanisms: Incorporates overvoltage, undervoltage, and overcurrent protection circuits to safeguard both the daughter card itself and connected system components from damage under abnormal operating conditions. Diagnostic Capabilities: Features built-in diagnostic functions including open circuit detection for connected inputs, supporting efficient troubleshooting and minimizing system downtime. Industrial-Grade Construction: Utilizes high-quality composite resistors and other durable components with anti-corrosion conformal coating on circuit boards to enhance reliability in harsh industrial environments with dust, humidity, and temperature fluctuations. Backward Compatibility: Designed to be fully compatible with the first two revisions of the WNPS product line, allowing for seamless integration into existing Mark VI control systems without requiring extensive reconfiguration. Standard Assembly Design: Follows GE's rigorous manufacturing standards for turbine control components, ensuring consistent performance and reliability across all units.
interface *Output method: rear output *Fast Ethernet: 3 slots, each slot supports 8 ports, with optional optical and electrical options *Gigabit Ethernet: Provides 4 1000Base SFP slots *CONSOLE port: RS232 (RJ45) *Alarm port: 5.08mm spacing 3-pin Phoenix wiring terminal, 250VAC/220VDC 2 A cable *Twisted pair cable: 100m *Multimode fiber: 1310nm, 2km (100Mbps); 1310nm, 500m (gigabit) *Single mode fiber: 1310nm, 0-40km; 1550nm, 0-80km source *Input voltage: 110-220VDC/VAC, redundant input *Connection terminal: 5.08mm spacing 5-pin Phoenix wiring terminal *Power:<40W mechanical properties *Case: Aluminum model with fanless design *Protection level: IP30 *Installation method: 19 inch 1U rack type *Shell size: 440 mm * 44.5 mm * 370 mm (W * H * D), as shown in the attached image *Impact, vibration, and drop: meet the requirements of IEC61850-3 5.5 CM level *Weight: approximately 4.3kg
