IS200JPDMG1ACC S1AT005 GE input/output (I/O) module new in stock
IS200JPDMG1ACC S1AT005 is essential for applications such as gas turbine control, steam turbine control, power generation facilities, oil and gas refineries, chemical and petrochemical plants, and other heavy industrial environments requiring reliable power distribution to control system components.
GE IS200JPDMG1ACC S1AT005 Technical Specifications Brand & Model Brand: GE Boards & Turbine Control (General Electric) Model: IS200JPDMG1ACC S1AT005 Series: Mark VI IS200 Speedtronic Product Type: Jumper Power Distribution Card (JPDM) specifically designed for GE's Speedtronic Mark VI turbine control system, providing reliable 28V DC power distribution to various system components with flexible bus configuration options Physical Dimensions & Weight Dimensions (L×W×H): 200 mm × 150 mm × 50 mm (7.87 inches × 5.91 inches × 1.97 inches) Net Weight: Approximately 0.5 kg (1.1 lbs) for easy handling and installation in control cabinets Mounting: DIN-rail mounting for secure integration with standard industrial cabinet configurations Housing: Rugged industrial-grade printed circuit board (PCB) with flame-retardant coating, built to withstand harsh industrial environments Protection Rating: IP20 front panel protection against dust and solid objects; compliant with industrial safety standards for electrical equipment Core Technical Parameters Input Voltage: 28V DC power supply for reliable operation in industrial control systems Power Buses: Maintains three distinct power buses (R, S, T) with jumper options for single bus configuration with redundant power supplies Connector Type: Three 2-pin Mate-N-Lok connectors (JCR, JCS, JCT) for power distribution Connector Current Rating: 25A per connector for high-power applications Maximum Total Current: 35 Amps for robust power delivery to multiple system components Operating Temperature: -30°C to +65°C (-22°F to +149°F) for operation in extreme industrial environments Storage Temperature: -40°C to +85°C (-40°F to +185°F) for extended environmental tolerance Relative Humidity: 5% to 95% non-condensing for reliable performance in varying humidity conditions Certifications: Class 1 Div 2 approval rating for use in hazardous industrial locations Safety Features: Fuse protection for all outputs to prevent damage from overcurrent conditions Key Product Features Flexible Power Distribution: Three distinct power buses (R, S, T) with jumper options for configuring as a single bus with redundant power supplies, ensuring system reliability and flexibility High Power Capacity: 25A per connector and 35A total current rating to support multiple high-power system components simultaneously Fuse Protection: Individual fuse protection for each output connector prevents damage from overcurrent and short circuits, enhancing system safety Easy Integration: DIN-rail mounting design and standard Mate-N-Lok connectors enable quick and secure installation in Mark VI control system racks Industrial-Grade Design: Rugged PCB construction with wide temperature range and humidity tolerance ensures reliable operation in harsh industrial environments Diagnostic Capabilities: Built-in self-diagnostic features monitor power distribution status and provide real-time alerts for potential issues, minimizing downtime Mark VI Compatibility: Specifically designed for seamless integration with GE's Speedtronic Mark VI turbine control system, ensuring plug-and-play functionality Safety Compliance: Class 1 Div 2 approval rating makes it suitable for use in hazardous locations, meeting strict industrial safety standards
