IS200ESYSH1ABB GE I/O Board

IS200ESYSH1ABB Basic Info
Brand: General Electric (GE)
Model No.:IS200ESYSH1ABB
Order Code:IS200ESYSH1ABB
Product Name:EX2100e ESYS System Signal Interface I/O Board
Country of Origin:USA
HS Code:8538909100
Dimension:242mm×150mm×30mm
Net Weight:1.08kg

Input Parameter
1. Analog Input: Multi-channel generator PT/CT secondary AC voltage & current input
2. Digital Input: Field breaker status, field fault trip contact dry contact input (24VDC signal level)
3. Backplane Bus Input: HSSL high-speed bus signal from main controller
Output Parameter
1. Analog Output: Regulated analog control signal to excitation power amplifier unit
2. Digital Output: Relay dry contact output for excitation switch-on/off control
3. Bus Output: Internal backplane data transmission to auxiliary boards
Working Temp:-30℃~+65℃

interface
*Output method: rear output
*Fast Ethernet: 3 slots, each slot supports 8 ports, with optional optical and electrical options
*Gigabit Ethernet: Provides 4 1000Base SFP slots
*CONSOLE port: RS232 (RJ45)
*Alarm port: 5.08mm spacing 3-pin Phoenix wiring terminal, 250VAC/220VDC 2 A
cable
*Twisted pair cable: 100m
*Multimode fiber: 1310nm, 2km (100Mbps); 1310nm, 500m (gigabit)
*Single mode fiber: 1310nm, 0-40km; 1550nm, 0-80km
source
*Input voltage: 110-220VDC/VAC, redundant input
*Connection terminal: 5.08mm spacing 5-pin Phoenix wiring terminal
*Power:<40W
mechanical properties
*Case: Aluminum model with fanless design
*Protection level: IP30
*Installation method: 19 inch 1U rack type
*Shell size: 440 mm * 44.5 mm * 370 mm (W * H * D), as shown in the attached image
*Impact, vibration, and drop: meet the requirements of IEC61850-3 5.5 CM level
*Weight: approximately 4.3kg

*10 Mbps forwarding speed: 14881pps
*100Mbps forwarding speed: 148810pps
*Transmission method: storage and forwarding
*System exchange bandwidth: 1.6Gbps
*Cache size: 1Mbits
*MAC address table: 2K
