The IC800SSI228RD2-CE is a high-performance 28-amp servo controller from the GE Fanuc S2K series (now under Emerson Process Management), specifically designed for precise motion control of MTR series servo motors in industrial automation applications.
IC800SSI228RD2-CE - GE Fanuc (Emerson) S2K Series Servo Controller Overview The IC800SSI228RD2-CE is a high-performance 28-amp servo controller from the GE Fanuc S2K series (now under Emerson Process Management), specifically designed for precise motion control of MTR series servo motors in industrial automation applications. It integrates advanced control algorithms with robust hardware design to deliver accurate position, speed, and torque regulation, making it an ideal solution for applications requiring high dynamic response and repeatability such as robotics, packaging machinery, material handling systems, and CNC machine tools. The "-CE" suffix indicates a specific configuration variant with enhanced compatibility and performance optimization for industrial environments. Technical Specifications Brand & Manufacturer The product is manufactured by GE Fanuc (now part of Emerson Process Management), a leading provider of industrial automation and motion control solutions renowned for reliability and innovation in factory automation systems. Model Number The full model number is IC800SSI228RD2-CE, where: IC800: Denotes the industrial control product series SSI: Indicates Servo System Interface compatibility 228: Signifies 28-amp current rating RD2: Represents DeviceNet communication protocol support and specific hardware revision -CE: Designates a special configuration variant with enhanced industrial compatibility Physical Specifications Dimensions The servo controller features a compact DIN rail-mountable design with dimensions of 190 mm × 70 mm × 30 mm (7.48 in × 2.76 in × 1.18 in), optimized for space-efficient installation in electrical control cabinets and industrial enclosures. Weight The unit has a net weight of 1.5 kg (3.3 lbs) without additional accessories, facilitating easy handling during installation and maintenance. Mounting It utilizes standard DIN rail mounting (compatible with EN 50022-35 standards), ensuring secure and straightforward integration into industrial control systems with quick installation and removal capabilities. Core Features Precision Motion Control: Implements advanced PID control algorithms with auto-tuning functionality to deliver highly accurate position, speed, and torque regulation with a speed resolution of 0.1 rpm for smooth and precise motor operation. DeviceNet Communication: Equipped with integrated DeviceNet network interface for seamless connectivity to PLC systems, enabling real-time data exchange, remote configuration, and diagnostic capabilities in industrial automation networks. Comprehensive I/O Capabilities: Features configurable digital input/output points for direct connection to limit switches, sensors, and actuators, supporting flexible integration with external control devices and safety interlock systems. Dual Control Modes: Supports both single-axis and dual-axis control configurations, providing versatility for various motion control system architectures. 24 VDC Motor Brake Support: Includes dedicated outputs for controlling 24 VDC motor brakes, ensuring safe and reliable holding of loads in vertical applications or during emergency stops. Robust Protection Mechanisms: Incorporates comprehensive protection features such as overcurrent, overvoltage, undervoltage, overheating, and short-circuit protection to safeguard both the controller and connected servo motor from damage under abnormal operating conditions. Simplified Maintenance: Built-in fault diagnostic capabilities with LED status indicators and event logging for quick troubleshooting and system optimization, minimizing downtime in industrial production environments.
interface *Output method: rear output *Fast Ethernet: 3 slots, each slot supports 8 ports, with optional optical and electrical options *Gigabit Ethernet: Provides 4 1000Base SFP slots *CONSOLE port: RS232 (RJ45) *Alarm port: 5.08mm spacing 3-pin Phoenix wiring terminal, 250VAC/220VDC 2 A cable *Twisted pair cable: 100m *Multimode fiber: 1310nm, 2km (100Mbps); 1310nm, 500m (gigabit) *Single mode fiber: 1310nm, 0-40km; 1550nm, 0-80km source *Input voltage: 110-220VDC/VAC, redundant input *Connection terminal: 5.08mm spacing 5-pin Phoenix wiring terminal *Power:<40W mechanical properties *Case: Aluminum model with fanless design *Protection level: IP30 *Installation method: 19 inch 1U rack type *Shell size: 440 mm * 44.5 mm * 370 mm (W * H * D), as shown in the attached image *Impact, vibration, and drop: meet the requirements of IEC61850-3 5.5 CM level *Weight: approximately 4.3kg
