The IC200CPUE05 is a high-performance programmable logic controller (PLC) CPU module from the GE Fanuc VersaMax series (now part of Emerson Automation Solutions), featuring an embedded Ethernet interface for seamless industrial network integration.
IC200CPUE05 - GE Fanuc VersaMax CPU with Embedded Ethernet Interface Overview The IC200CPUE05 is a high-performance programmable logic controller (PLC) CPU module from the GE Fanuc VersaMax series (now part of Emerson Automation Solutions), featuring an embedded Ethernet interface for seamless industrial network integration. It delivers powerful control capabilities in a compact, user-friendly design, supporting up to 64 expansion modules and 2048 I/O points to accommodate diverse automation applications across manufacturing, process control, and industrial machinery sectors. This CPU combines non-volatile flash memory for program storage with battery-backed RAM for data retention, ensuring reliable operation and data integrity even during power interruptions. Technical Specifications Brand & Manufacturer The product is manufactured by General Electric (GE), specifically under the GE Fanuc Automation division (now integrated into Emerson Automation Solutions), a global leader in industrial control systems renowned for reliability and innovation in automation technology. Model Number The full model designation is IC200CPUE05, where: IC200: Denotes the industrial control product series within the VersaMax platform CPU: Identifies the Central Processing Unit functionality E05: Signifies the specific model variant with embedded Ethernet interface and enhanced communication capabilities Physical Specifications Dimensions The CPU module features a compact design with dimensions of 126 mm × 128 mm × 69.1 mm (4.95 in × 5.04 in × 2.72 in), with the width measurement aligned along the DIN rail mounting direction for space-efficient installation in control cabinets.
Weight The unit has a net weight of 0.4 kg (0.88 lbs) without additional accessories, facilitating easy handling during installation, maintenance, and system reconfiguration. Mounting It utilizes standard DIN rail mounting (compatible with EN 50022 standards) for secure and straightforward integration into industrial control systems, allowing quick installation and removal without specialized tools. Core Features Integrated Communication Interfaces: Equipped with one RS-232 serial port, one RS-485 serial port, and one embedded Ethernet interface (RJ-45 connector, UTP) for versatile connectivity to human-machine interfaces (HMIs), other PLCs, and industrial networks. Powerful Processing Capabilities: Features a high-performance 32-bit processor with a typical Boolean execution speed of 0.8 ms/K and support for floating-point arithmetic, enabling efficient execution of complex control algorithms and mathematical operations. Extensive I/O Expansion: Supports up to 64 expansion modules and 2048 I/O points (digital and analog), providing flexible configuration options to match specific application requirements. Dual Memory Architecture: Combines 64 KB configurable user memory (for application programs, hardware configuration, and data registers) with non-volatile system flash memory and battery-backed RAM for reliable program storage and data retention. Advanced Network Functions: The Ethernet interface supports 10 Mbps data rate (half- or full-duplex), up to 8 SRTP server connections, and 32 Ethernet Global Data (EGD) configuration-based exchanges with NTP time synchronization capability. Real-Time Clock: Incorporates a precision real-time clock with 100 ppm accuracy (±9 seconds per day) for time-critical control functions and event logging. Data Retention: Features a built-in supercapacitor that provides up to 1 hour of backup power for the real-time clock and RAM data, complemented by an optional battery for extended retention periods. Diagnostic Capabilities: The RS-232 serial port can be configured for Local Station manager operation to provide access to diagnostic information about the Ethernet interface, facilitating troubleshooting and system monitoring.
interface *Output method: rear output *Fast Ethernet: 3 slots, each slot supports 8 ports, with optional optical and electrical options *Gigabit Ethernet: Provides 4 1000Base SFP slots *CONSOLE port: RS232 (RJ45) *Alarm port: 5.08mm spacing 3-pin Phoenix wiring terminal, 250VAC/220VDC 2 A cable *Twisted pair cable: 100m *Multimode fiber: 1310nm, 2km (100Mbps); 1310nm, 500m (gigabit) *Single mode fiber: 1310nm, 0-40km; 1550nm, 0-80km source *Input voltage: 110-220VDC/VAC, redundant input *Connection terminal: 5.08mm spacing 5-pin Phoenix wiring terminal *Power:<40W mechanical properties *Case: Aluminum model with fanless design *Protection level: IP30 *Installation method: 19 inch 1U rack type *Shell size: 440 mm * 44.5 mm * 370 mm (W * H * D), as shown in the attached image *Impact, vibration, and drop: meet the requirements of IEC61850-3 5.5 CM level *Weight: approximately 4.3kg
