HYDRAN 201TI GE Single Gas Transformer DGA

HYDRAN 201TI GE Technical Specifications and Introduction
Technical Parameters
Basic Information: Model: HYDRAN 201TI; Brand: GE; Origin: USA.
Weight: Approximately 5.6kg, with a sturdy structure suitable for on-site transformer valve installation.
Dimensions: 263mm × 58mm × 28mm (L×W×H), cylindrical design with an overall length of 257mm and diameter of 178mm, compatible with single transformer oil valve mounting.
HS Code: 8537109090, applicable to industrial monitoring instruments and subject to customs regulation adjustments.
Temperature Parameters: Operating temperature ranges from -40°C to +55°C, storage temperature ranges from -40°C to +70°C, adaptable to industrial ambient conditions with 0-95% non-condensing relative humidity; internal sensor temperature is maintained between 25°C and 45°C for stable operation.
Input Parameters: Working power supports industrial standard power supply, with integrated sensor inputs for gas level, sensor temperature and heating plate temperature; it uses dynamic oil sampling technology, requiring no external sampling pumps or extra piping.

Output Parameters: Standard local analog output is 0-1mA non-isolated (0-2000 ppm range, H2 equivalent); optional 4-20mA isolated output (1500V RMS) is available. It is equipped with 3 SPDT (type C) alarm contacts, rated 60W, 125VA, 220VDC, 250VAC, supporting two configurable alarm levels.
Product Features: High reliability and stability, with over 30,000 units sold worldwide, adopting improved sensors and updated electronic boards to meet RoHS compliance.
Dual gas sensor options: "Hydran composite gas" sensor (responds 100% to H2, sensitive to CO, C2H2 and C2H4) and "hydrogen only" sensor, covering main transformer fault root causes.
Easy installation, mounted on a single transformer oil valve without extra piping or pumps, suitable for on-site transformer monitoring.
Strong anti-interference performance, complying with EMC directive 89/336/EEC, resistant to electromagnetic interference in industrial power grid environments.
IP56 (NEMA 4X) protection grade, with a cylindrical aluminum enclosure to prevent dust and water ingress, suitable for harsh on-site conditions.
Equipped with backlit LCD display and 6-key keypad for easy operation; supports Modbus® protocol over isolated RS-485 and local USB port for data interaction, compatible with GE Perception™ fleet software.
