Honeywell 8C-PCNT01 pulse counter/timer module new brand

Honeywell 8C-PCNT01 Product Introduction & Technical Parameters
Brand: Honeywell
Model: 8C-PCNT01
Product Name: Pulse Counter / Timer Module
Dimensions:Approx. 130 mm (H) × 125 mm (W) × 35 mm (D); Series 8 IOTA form factor.
Weight: Approx. 0.5 kg (net).
Country of Origin: United States.
HS Code (Customs Code):  8537101190

Temperature Parameters:
Operating Temperature: -10°C to +60°C
Storage Temperature: -40°C to +85°C
Relative Humidity: 5%–95% non-condensing
Input:
Power Input: 24V DC (from system backplane); Power Consumption: ≤6W
Pulse Inputs: 8-channel isolated pulse inputs (4 differential, 4 single-ended)
Input Type: Optically isolated (500V RMS), high-impedance
Frequency Range: 0–1 MHz (single channel); 0–10 kHz (dual pulse)
Input Voltage: 24V DC ±10%
Output:
- Digital Outputs: 2 configurable transistor/open-collector outputs (for alarms/control)
- Communication: System bus to C300 controller; supports Modbus TCP/EtherNet/IP
- Status Indicators: LED for power, run, fault, and channel activity
Features:
16-bit high-resolution counting; ±1 pulse accuracy
Supports up/down/bidirectional counting modes per channel
Isolated field-to-logic (500V RMS) for noise immunity
High-speed input up to 1 MHz for fast pulse capture
Configurable threshold alarms and preset counter values
Plug-and-play IOTA design for easy installation/replacement
Conformal coating for harsh industrial environments
CE, UL, C-UL, RoHS compliant
Seamless integration with Honeywell Experion PKS C300 systems
Self-diagnostics, fault logging, and real-time status monitoring

interface
*Output method: rear output
*Fast Ethernet: 3 slots, each slot supports 8 ports, with optional optical and electrical options
*Gigabit Ethernet: Provides 4 1000Base SFP slots
*CONSOLE port: RS232 (RJ45)
*Alarm port: 5.08mm spacing 3-pin Phoenix wiring terminal, 250VAC/220VDC 2 A
cable
*Twisted pair cable: 100m
*Multimode fiber: 1310nm, 2km (100Mbps); 1310nm, 500m (gigabit)
*Single mode fiber: 1310nm, 0-40km; 1550nm, 0-80km
source
*Input voltage: 110-220VDC/VAC, redundant input
*Connection terminal: 5.08mm spacing 5-pin Phoenix wiring terminal
*Power:<40W
mechanical properties
*Case: Aluminum model with fanless design
*Protection level: IP30
*Installation method: 19 inch 1U rack type
*Shell size: 440 mm * 44.5 mm * 370 mm (W * H * D), as shown in the attached image
*Impact, vibration, and drop: meet the requirements of IEC61850-3 5.5 CM level
*Weight: approximately 4.3kg

*10 Mbps forwarding speed: 14881pps
*100Mbps forwarding speed: 148810pps
*Transmission method: storage and forwarding
*System exchange bandwidth: 1.6Gbps
*Cache size: 1Mbits
*MAC address table: 2K
