Honeywell 05701-A-0361 Engineering Card new in stock
The Honeywell 05701-A-0361 is a single channel control card for the System 57 gas detection system, featuring a 4-20 mA gas detector input, 3 Form C relay outputs, 1 4-20 mA analog output, LCD display, LED indicators, and Modbus RTU communication, designed for reliable monitoring of combustible or toxic gases in industrial applications.
Honeywell 05701-A-0361 Single Channel Control Card: Overview and Technical Specifications Brand and Model Information Brand: Honeywell (Zellweger Analytics, part of Honeywell Safety and Productivity Solutions)Model: 05701-A-0361Product Type: Single Channel Control Card for Gas Detection SystemsSeries: System 57 Gas Detection SystemApplication: Designed to provide comprehensive control, real-time display, and alarm management capabilities for a connected gas detector, specifically optimized for industrial environments requiring reliable monitoring of combustible or toxic gases, such as refineries, chemical plants, oil and gas facilities, and manufacturing sites Technical Specifications Physical and Environmental Specifications Dimensions: Standard System 57 card form factor, approximately 100 mm × 160 mm × 25 mm (3.94" × 6.30" × 0.98") Weight: Approximately 0.2 kg (0.44 lb) Operating Temperature: -20°C to +60°C (-4°F to +140°F) Storage Temperature: -40°C to +85°C (-40°F to +185°F) Humidity: 5% to 95% non-condensing, with protection against dust and moisture (IP20 enclosure rating for card, IP40 for system rack) Mounting: System 57 rack mounting (compatible with standard 19" rack enclosures) for seamless integration into gas detection control panels Power Consumption: 5 VA at 18-32V DC (±10%) operating voltage Input Specifications Gas Detector Input: Single channel for connecting to Honeywell Zellweger Analytics gas detectors, supporting catalytic bead, infrared, or electrochemical sensor technologies Sensor Signal Type: 4-20 mA analog input for gas concentration measurement, with adjustable input range based on detector type (0-100% LEL for combustible gases, 0-100 ppm for toxic gases) Detector Power Supply: Built-in 24V DC power supply for powering 2-wire and 3-wire field gas detectors, with short-circuit and overcurrent protection Switch Inputs: 2 dry contact inputs for external alarm or status monitoring, with 250V AC/30V DC, 5A maximum rating Communication Input: RS-485 Modbus RTU input for system configuration and data exchange with engineering tools Output and Communication Specifications Relay Outputs: 3 independent Form C (changeover) relay outputs with 5A/250V AC and 5A/30V DC rating, configurable for alarm (low, high), fault, and warning conditions Analog Output: 1 isolated 4-20 mA analog output, user-configurable to represent gas concentration (0-100% LEL/ppm) or detector status Digital Display: Four-part liquid crystal display (LCD) consisting of a 25-segment analog bar graph, four-character digital concentration readout, four-character information display, and icon section for visual status indication (power, alarm, fault, calibration) LED Indicators: Multi-color LED indicators for power (green), alarm (red), warning (yellow), and fault (amber) conditions for quick visual system diagnostics Push-button Controls: Dedicated push-button for alarm reset and card selection when used with the System 57 Engineering Card Communication Interfaces: RS-485 Modbus RTU for integration with PLCs, SCADA systems, and Building Management Systems (BMS)
interface *Output method: rear output *Fast Ethernet: 3 slots, each slot supports 8 ports, with optional optical and electrical options *Gigabit Ethernet: Provides 4 1000Base SFP slots *CONSOLE port: RS232 (RJ45) *Alarm port: 5.08mm spacing 3-pin Phoenix wiring terminal, 250VAC/220VDC 2 A cable *Twisted pair cable: 100m *Multimode fiber: 1310nm, 2km (100Mbps); 1310nm, 500m (gigabit) *Single mode fiber: 1310nm, 0-40km; 1550nm, 0-80km source *Input voltage: 110-220VDC/VAC, redundant input *Connection terminal: 5.08mm spacing 5-pin Phoenix wiring terminal *Power:<40W mechanical properties *Case: Aluminum model with fanless design *Protection level: IP30 *Installation method: 19 inch 1U rack type *Shell size: 440 mm * 44.5 mm * 370 mm (W * H * D), as shown in the attached image *Impact, vibration, and drop: meet the requirements of IEC61850-3 5.5 CM level *Weight: approximately 4.3kg
