HIMA F8627X Profibus-DP master module new in stock

HIMA F8627X Product Introduction & Technical Parameters
Brand: HIMA Paul Hildebrandt GmbH + Co KG
Model: F8627X
Product Name: Profibus-DP Master Communication Module (HIMax Platform)
Dimensions:19" rack-mount module; 3 Height Units (HU, 3 × 44.45 mm) × 4 Width Units (WU, 4 × 5.08 mm); Standard form factor for HIMax chassis.
Weight  Approx. 1.0 kg (net); shipping weight ~1.3 kg.
Country of Origin  Germany.
HS Code (Customs Code)   8538900000

Temperature & Humidity
Operating Temperature: 0°C to +60°C (industrial range); extended option: -25°C to +70°C for harsh environments.
Storage Temperature: -40°C to +85°C.
Relative Humidity: 5%–95% non-condensing.
Input
Power Supply: 24 V DC (18–32 V range); Power Consumption < 12 W.
Communication Inputs: 2× isolated Profibus-DP master interfaces (9-pin D-SUB male, DP-V0/V1 support).
Baud Rate: 9.6 kbps to 12 Mbps (auto/manual configuration).
Electrical Isolation: ≥500 VRMS between channels and backplane.
Output
Communication Outputs: Profibus-DP (master, up to 126 slaves per channel, total 252).
Diagnostics: Real-time bus status, slave health, error counting, and status reporting to HIMA Safety Suite via internal system bus.
Status Indicators: Module health LEDs (power, communication, fault, status) integrated into HIMax chassis.
Features
SIL 3 Certification: Compliant with IEC 61508, IEC 61511, EN 50156; ATEX certification for hazardous area deployment (when properly installed).
Dual-Channel Redundancy: Isolated channels with channel-to-channel comparison; data mismatch triggers safe shutdown, ensuring >99% diagnostic coverage.
Protocol Support: Profibus-DP (master), SafeEthernet, OPC DA/A&E, Modbus TCP (slave), ELOP II programming via Ethernet (v4.1+).
High-Speed Communication: Up to 100 Mbps Ethernet (100BASE-TX, RJ45) for auxiliary communication.
Seamless Integration: Native HIMax/QMR architecture; no external converters needed; GSD file configuration via HIMA Safety Suite.
Robust Diagnostics: Bus error monitoring, fault logging, and predictive maintenance alerts; supports acyclic data exchange for device status retrieval.
Environmental Robustness: Conformal coating as standard; IP20 rating for industrial installation; resistant to dust, moisture, and electromagnetic interference.
Compliance: CE, RoHS compliant; designed for long-term reliability in mission-critical applications.


interface
*Output method: rear output
*Fast Ethernet: 3 slots, each slot supports 8 ports, with optional optical and electrical options
*Gigabit Ethernet: Provides 4 1000Base SFP slots
*CONSOLE port: RS232 (RJ45)
*Alarm port: 5.08mm spacing 3-pin Phoenix wiring terminal, 250VAC/220VDC 2 A
cable
*Twisted pair cable: 100m
*Multimode fiber: 1310nm, 2km (100Mbps); 1310nm, 500m (gigabit)
*Single mode fiber: 1310nm, 0-40km; 1550nm, 0-80km
source
*Input voltage: 110-220VDC/VAC, redundant input
*Connection terminal: 5.08mm spacing 5-pin Phoenix wiring terminal
*Power:<40W
mechanical properties
*Case: Aluminum model with fanless design
*Protection level: IP30
*Installation method: 19 inch 1U rack type
*Shell size: 440 mm * 44.5 mm * 370 mm (W * H * D), as shown in the attached image
*Impact, vibration, and drop: meet the requirements of IEC61850-3 5.5 CM level
*Weight: approximately 4.3kg

*10 Mbps forwarding speed: 14881pps
*100Mbps forwarding speed: 148810pps
*Transmission method: storage and forwarding
*System exchange bandwidth: 1.6Gbps
*Cache size: 1Mbits
*MAC address table: 2K
