The H6200A is a rugged extreme touchscreen display belonging to the Schneider Electric Harmony GTUX series, specifically engineered for harsh outdoor industrial environments. Featuring a durable coated structure and high-brightness display, this 15.6-inch touch panel serves as a reliable human-machine interface (HMI) solution, ensuring clear visibility and stable operation even under direct sunlight and adverse environmental conditions. Its modular design facilitates convenient installation and maintenance, making it ideal for capital asset operation and maintenance scenarios that demand high reliability and environmental adaptability.
HIMA H6200A Product Introduction & Technical Specifications 1. Product Overview The H6200A is a rugged extreme touchscreen display belonging to the Schneider Electric Harmony GTUX series, specifically engineered for harsh outdoor industrial environments. Featuring a durable coated structure and high-brightness display, this 15.6-inch touch panel serves as a reliable human-machine interface (HMI) solution, ensuring clear visibility and stable operation even under direct sunlight and adverse environmental conditions. Its modular design facilitates convenient installation and maintenance, making it ideal for capital asset operation and maintenance scenarios that demand high reliability and environmental adaptability. 2. Key Features - Rugged Outdoor Adaptability: Built with a robust structure and UV-resistant coating, capable of withstanding harsh outdoor conditions such as direct sunlight, large temperature fluctuations, and dusty or wet environments. - High-Visibility Display: Equipped with a 1000 cd/m² high-brightness color TFT LCD screen, ensuring excellent readability even in bright daylight conditions. - Superior Protection Performance: Boasts IP66F and IP67F ingress protection ratings, achieving complete dust tightness and protection against temporary submersion in water, ensuring reliable operation in harsh industrial settings. - Efficient Thermal Management: Adopts natural convection cooling technology, which effectively dissipates heat without additional cooling components, enhancing operational stability and reducing energy consumption. - Wide Voltage Adaptability: Supports a broad supply voltage range, enabling stable operation under fluctuating power supply conditions in industrial environments. - Optimized Power Consumption: Features a low power consumption of 12.5W, contributing to energy efficiency and reduced operational costs. 3. Technical Specifications 3.1 Display Parameters - Display Type: Color TFT LCD - Display Size: 15.6 inches - Pixel Resolution: 1366 x 768 pixels (FWXGA) - Color Depth: 262,144 colors - Luminance: 1000 cd/m² (equivalent to 92.90 fc) - Backlight Lifespan: 50,000 hours 3.2 Touch Panel Parameters - Touch Technology: Single-touch analog resistive - Touch Resolution: 1024 x 1024 3.3 Power Supply Parameters - Rated Supply Voltage: 12 - 24 V DC - Supply Voltage Limits: 10.8 - 28.8 V DC - Power Consumption: 12.5 W - Inrush Current: 30 A 3.4 Mechanical Parameters - Overall Dimensions (W x H x D): 408 mm (16.06 in) x 264 mm (10.39 in) x 68 mm (2.68 in) - Panel Cut-Out Dimensions: 394 (+1/-0) mm x 250 (+1/-0) mm - Net Weight: 4.8 kg (10.58 lb) - Mounting Angle: 0 - 30 degrees 3.5 Environmental Parameters - Operating Ambient Temperature: -20 °C to 60 °C (-4 °F to 140 °F) (compliant with EN 61131-2) - Storage Ambient Temperature: -20 °C to 60 °C (-4 °F to 140 °F) - Relative Humidity: 10% - 90% (non-condensing) - Operating Altitude: Up to 2000 m (6561.68 ft) - Vibration Resistance: 7 mm constant amplitude (5 - 9 Hz); 9.8 m/s² (9 - 150 Hz) (compliant with EN/IEC 61131-2) - Shock Resistance: 147 m/s² (compliant with EN/IEC 61131-2) - Electrostatic Discharge Immunity: Test Level 3 (compliant with EN/IEC 61000-4-2) - Environmental Adaptability: Corrosive gas free, UV resistant 4. Compliance & Certifications The H6200A complies with multiple international industry standards and holds relevant certifications, including UL 508, ANSI/ISA 12-12-01, Class I Division 2, CSA C22.2 No. 213, CSA C22.2 No. 142, IEC 61132-2, KC, CE, RCM, and cULus. These certifications ensure the product's safety, reliability, and compatibility in global industrial applications.
interface *Output method: rear output *Fast Ethernet: 3 slots, each slot supports 8 ports, with optional optical and electrical options *Gigabit Ethernet: Provides 4 1000Base SFP slots *CONSOLE port: RS232 (RJ45) *Alarm port: 5.08mm spacing 3-pin Phoenix wiring terminal, 250VAC/220VDC 2 A cable *Twisted pair cable: 100m *Multimode fiber: 1310nm, 2km (100Mbps); 1310nm, 500m (gigabit) *Single mode fiber: 1310nm, 0-40km; 1550nm, 0-80km source *Input voltage: 110-220VDC/VAC, redundant input *Connection terminal: 5.08mm spacing 5-pin Phoenix wiring terminal *Power:<40W mechanical properties *Case: Aluminum model with fanless design *Protection level: IP30 *Installation method: 19 inch 1U rack type *Shell size: 440 mm * 44.5 mm * 370 mm (W * H * D), as shown in the attached image *Impact, vibration, and drop: meet the requirements of IEC61850-3 5.5 CM level *Weight: approximately 4.3kg
