FOXBORO RH924UQ Control Module

No.939440
The FOXBORO RH924UQ is a high-performance control module designed for industrial automation applications, ensuring precise process control across various industries.
  • FOXBORO RH924UQ Control Module
  • FOXBORO RH924UQ Control Module
  • FOXBORO RH924UQ Control Module
  • FOXBORO RH924UQ Control Module
  • Description

  • Here's how it works

  • SPECIFICATION

Operating Voltage:220 V

Output Frequency:50 kHz

Certified Product:RH924UQ

Series:RH924UQ

Material Coding:RH924UQ

    Unmatched Performance: The RH924UQ is engineered with advanced technology to deliver exceptional performance and reliability in challenging industrial environments.

    Precision Control: Equipped with state-of-the-art algorithms, this module ensures accurate and responsive process control, enhancing operational efficiency.

    Durable Construction: Designed with robust materials and manufacturing processes, the RH924UQ stands up to harsh conditions, guaranteeing long-lasting service life.

    Easy Integration: The module seamlessly integrates into existing systems, reducing setup time and minimizing downtime during installation.

    Comprehensive Support: Benefitting from the extensive expertise of the FOXBORO brand, users receive unparalleled technical support and access to a wide range of compatible accessories.

FOXBORO RH924UQ

FOXBORO RH924UQ

interface
*Output method: rear output
*Fast Ethernet: 3 slots, each slot supports 8 ports, with optional optical and electrical options
*Gigabit Ethernet: Provides 4 1000Base SFP slots
*CONSOLE port: RS232 (RJ45)
*Alarm port: 5.08mm spacing 3-pin Phoenix wiring terminal, 250VAC/220VDC 2 A
cable
*Twisted pair cable: 100m
*Multimode fiber: 1310nm, 2km (100Mbps); 1310nm, 500m (gigabit)
*Single mode fiber: 1310nm, 0-40km; 1550nm, 0-80km
source
*Input voltage: 110-220VDC/VAC, redundant input
*Connection terminal: 5.08mm spacing 5-pin Phoenix wiring terminal
*Power:<40W
mechanical properties
*Case: Aluminum model with fanless design
*Protection level: IP30
*Installation method: 19 inch 1U rack type
*Shell size: 440 mm * 44.5 mm * 370 mm (W * H * D), as shown in the attached image
*Impact, vibration, and drop: meet the requirements of IEC61850-3 5.5 CM level
*Weight: approximately 4.3kg
*10 Mbps forwarding speed: 14881pps
*100Mbps forwarding speed: 148810pps
*Transmission method: storage and forwarding
*System exchange bandwidth: 1.6Gbps
*Cache size: 1Mbits
*MAC address table: 2K
