Emerson VE3008 MQ Controller

Emerson DeltaV VE3008 Technical Specifications
Brand: Emerson (DeltaV)
Model: VE3008
Order No.: VE3008

Product Name: DeltaV MQ Controller Module
Origin: United States
HS Code: 85389091
Dimensions (W×H×D): 254 × 203 × 89 mm
Weight: 1.5 kg
Input: 24 VDC (16–30 VDC), 5 W typical; dual RJ45 (10/100 Mbps Ethernet)
Output: 48 MB user memory; supports Modbus TCP/IP, HART; redundant control network
Operating Temp: -40°C to +70°C
Safety: SIL 2 certified; IP20 (panel mount)

interface
*Output method: rear output
*Fast Ethernet: 3 slots, each slot supports 8 ports, with optional optical and electrical options
*Gigabit Ethernet: Provides 4 1000Base SFP slots
*CONSOLE port: RS232 (RJ45)
*Alarm port: 5.08mm spacing 3-pin Phoenix wiring terminal, 250VAC/220VDC 2 A
cable
*Twisted pair cable: 100m
*Multimode fiber: 1310nm, 2km (100Mbps); 1310nm, 500m (gigabit)
*Single mode fiber: 1310nm, 0-40km; 1550nm, 0-80km
source
*Input voltage: 110-220VDC/VAC, redundant input
*Connection terminal: 5.08mm spacing 5-pin Phoenix wiring terminal
*Power:<40W
mechanical properties
*Case: Aluminum model with fanless design
*Protection level: IP30
*Installation method: 19 inch 1U rack type
*Shell size: 440 mm * 44.5 mm * 370 mm (W * H * D), as shown in the attached image
*Impact, vibration, and drop: meet the requirements of IEC61850-3 5.5 CM level
*Weight: approximately 4.3kg

*10 Mbps forwarding speed: 14881pps
*100Mbps forwarding speed: 148810pps
*Transmission method: storage and forwarding
*System exchange bandwidth: 1.6Gbps
*Cache size: 1Mbits
*MAC address table: 2K
