DNP21-FBP 1SAJ230000R1003 ABB DCS MODULE

DNP21-FBP 1SAJ230000R1003 (ABB)
Technical Parameters
Brand: ABB
Model: DNP21-FBP 1SAJ230000R1003
Dimensions: Compact form factor tailored for fieldbus connection applications; specific dimensions align with standard ABB FieldBus Plug specifications, with a cable length of 0.25 meters (0.82 feet) for flexible installation in limited spaces
Weight: Approximately 0.09 kg (0.198 lbs) per unit, featuring a lightweight design that facilitates easy handling and installation without adding excess load to connected equipment
Origin: Manufactured in Germany, adhering to ABB’s global quality control standards for industrial communication components
HS Code: 85176200 (classified under industrial communication interfaces and fieldbus connection devices, compliant with international trade classification standards)

Temperature: Operating temperature range: -20°C to +60°C, suitable for typical industrial environments; storage temperature range: -40°C to +85°C, ensuring stable performance during long-term storage without degradation
Input: Compatible with DeviceNet communication protocol; supports connection to industrial field devices with standard signal interfaces; rated control supply voltage of 24V DC, ensuring stable power supply for reliable data transmission
Output: Provides stable digital communication signal output for real-time data exchange between field devices and the DeviceNet network; enables reliable signal transmission between connected equipment, supporting real-time control and monitoring functions in automated systems
Features: Dedicated to DeviceNet network connections, ensuring high-reliability data transmission; 0.25-meter fixed cable length for flexible installation in various industrial scenarios; lightweight and compact design for easy integration into existing automation systems; no DIN rail mounting required, simplifying installation procedures; low power loss (approximately 0.6W) for energy-efficient operation; compatible with ABB’s UMC series controllers and other industrial field devices; robust construction with IP20 ingress protection, suitable for harsh industrial operating environments; compliant with relevant international industrial communication standards and EU RoHS directive; easy plug-and-play installation, reducing commissioning time and improving work efficiency

interface
*Output method: rear output
*Fast Ethernet: 3 slots, each slot supports 8 ports, with optional optical and electrical options
*Gigabit Ethernet: Provides 4 1000Base SFP slots
*CONSOLE port: RS232 (RJ45)
*Alarm port: 5.08mm spacing 3-pin Phoenix wiring terminal, 250VAC/220VDC 2 A
cable
*Twisted pair cable: 100m
*Multimode fiber: 1310nm, 2km (100Mbps); 1310nm, 500m (gigabit)
*Single mode fiber: 1310nm, 0-40km; 1550nm, 0-80km
source
*Input voltage: 110-220VDC/VAC, redundant input
*Connection terminal: 5.08mm spacing 5-pin Phoenix wiring terminal
*Power:<40W
mechanical properties
*Case: Aluminum model with fanless design
*Protection level: IP30
*Installation method: 19 inch 1U rack type
*Shell size: 440 mm * 44.5 mm * 370 mm (W * H * D), as shown in the attached image
*Impact, vibration, and drop: meet the requirements of IEC61850-3 5.5 CM level
*Weight: approximately 4.3kg

*10 Mbps forwarding speed: 14881pps
*100Mbps forwarding speed: 148810pps
*Transmission method: storage and forwarding
*System exchange bandwidth: 1.6Gbps
*Cache size: 1Mbits
*MAC address table: 2K
