CS-TX3-3.81X2.54-64TW adopts a double row standard spacing of 3.81mm × 2.54mm, with a compact layout that can achieve multi contact connections in limited space. It has excellent conductivity and corrosion resistance, with an initial contact resistance of ≤ 20m Ω, reducing signal transmission loss.
Technical Specifications of CS-TX3-3.81X2.54-64TW (EATON)
Manufacturer: EATON
Product Model: CS-TX3-3.81X2.54-64TW
Product Type: Wire-to-Board Terminal Block (Insulation Displacement Connector, IDC)
Pin Pitch: 3.81 mm × 2.54 mm dual-row spacing, complying with industry standard pitch specifications for stable interconnection
Number of Contacts: 64 positions (32 positions per row), supporting high-density wiring requirements
Rated Current: 10 A (continuous operation at 25°C ambient temperature, derated at higher temperatures)
Rated Voltage: 300 V AC/DC (UL/CSA certified; 600 V AC/DC for IEC standard compliance)
Wire Gauge Compatibility:
Solid wire: 22–16 AWG (0.32–1.31 mm²)
Stranded wire: 22–16 AWG (0.28–1.31 mm²) with tin-plated or bare conductors
Contact Material: Phosphor bronze with tin plating (minimum 5 μm thickness) for excellent electrical conductivity and corrosion resistance
Insulation Material: High-temperature nylon 6.6 (UL94 V-0 flammability rating) for enhanced mechanical strength and thermal stability
Installation Method: Panel mount via screw fastening; compatible with standard DIN rail (35 mm) or direct mounting holes
Operating Temperature Range: -40°C to +105°C, suitable for harsh industrial environments
Storage Temperature Range: -55°C to +125°C, ensuring product integrity during transportation and storage
Protection Rating: IP20 (per IEC 60529) for protection against solid objects larger than 12.5 mm
Contact Resistance: Maximum 20 mΩ (initial, at 1 A test current) to minimize signal loss
Dielectric Strength: 1500 V AC for 1 minute (no breakdown or flashover)
Vibration Resistance: Complies with IEC 60068-2-6; 10–500 Hz, 1.5 mm amplitude (peak-to-peak)
Shock Resistance: Complies with IEC 60068-2-27; 15 g acceleration (11 ms duration)
Color: Natural nylon (off-white), with clear marking for contact position identification
Certifications: UL Recognized (File No. E174988), CSA Certified (File No. LR66478), IEC/EN 60947-1 compliant, RoHS 2.0 (2011/65/EU) certified for environmental friendliness
