CM3201 is widely used in production line automation, process control systems, building automation, energy management, and infrastructure projects, and can achieve digital signal acquisition of sensors, switches, and other equipment.
Technical Specifications of Schneider Electric CM3201
Brand & Model: Schneider Electric CM3201 (Intelligent Digital I/O Module)
Product Type: Compact digital input/output module for industrial automation systems, compatible with Schneider Electric Modicon M340/M580 PLC platforms
Power Supply: DC 24V ±10% (operating voltage range: 21.6V~26.4V); Power consumption: ≤8W (full load)
Input Specifications:
Digital Input Channels: 16 channels (isolated)
Input Type: NPN/PNP configurable (per channel)
Input Voltage Range: 10V~30VDC
Input Current: ≤5mA per channel
Response Time: ≤1ms (on/off transition)
Output Specifications:
Digital Output Channels: 16 channels (isolated)
Output Type: Transistor (sourcing/sinking configurable)
Maximum Switching Capacity: 0.5A @ 30VDC per channel; 4A total per module
Short-Circuit Protection: Built-in overcurrent protection for each output channel
Temperature Ratings:
Operating Temperature: -25°C to +70°C (-13°F to +158°F)
Storage Temperature: -40°C to +85°C (-40°F to +185°F)
Environmental Resistance:
Humidity: 5%~95% RH (non-condensing, up to 40°C)
Vibration Resistance: 10g (10~150Hz, IEC 61010-1)
Shock Resistance: 30g (11ms duration, IEC 61010-1)
Protection Rating: IP20 (panel-mounted, dust-protected)
Mounting Type: DIN rail mounting (35mm standard rail, EN 50022)
Dimensions (W×H×D): 36mm × 100mm × 120mm (1.42in × 3.94in × 4.72in)
Weight: Approx. 180g (0.40lb)
Material: Flame-retardant PC/ABS plastic (UL94 V-0 rating)
Communication Interface: Backplane communication (integrated with Modicon PLC bus, no external wiring required)
Certifications: CE, UL, CSA, RoHS compliant
Application Range: Suitable for industrial automation scenarios including manufacturing lines, process control systems, building automation, energy management, and infrastructure projects—ideal for digital signal acquisition (sensors, switches) and control of actuators (solenoids, relays, small motors) in harsh industrial environments.
