CCC30-2-P 3BDH000549R2 is engineered to support various standard industrial communication protocols, such as Modbus RTU, ensuring seamless interoperability with different devices and systems.
ABB CCC30-2-P 3BDH000549R2 Product Overview & Technical Specifications Brand & Model This product is CCC30-2-P 3BDH000549R2. It is a key component within ABB's Advant Controller 800xA (AC 800xA) series, designed for industrial automation and control systems. Physical Specifications The CCC30-2-P 3BDH000549R2 communication interface module features a compact, rack-mountable form factor. Its approximate dimensions are 150 mm (W) x 300 mm (D) x 50 mm (H), and it has a net weight of around 0.8 kg. This module is typically installed in a standard 19-inch cabinet or subrack. Input & Output Interface Functioning as a communication module, the CI532V02 does not feature traditional analog or digital I/O channels for field devices. Instead, it is equipped with communication ports to facilitate data exchange. It supports serial communication interfaces, commonly including RS-232 and RS-485 ports, enabling connectivity to a wide range of field devices, third-party systems, or other controllers. Key Features Communication Protocol Support: The module is engineered to support various standard industrial communication protocols, such as Modbus RTU, ensuring seamless interoperability with different devices and systems. High Reliability: Built for industrial environments, it offers robust performance with high resistance to electromagnetic interference (EMI) and electrical noise, ensuring stable operation in demanding conditions. Redundancy Capability: It supports redundant communication paths, which is critical for enhancing system availability and minimizing downtime in mission-critical applications. Easy Integration & Configuration: The module is designed for straightforward integration into the AC 800xA system, with configuration managed through ABB's Control Builder M software, allowing for flexible setup of communication parameters. Diagnostics & Status Monitoring: It provides comprehensive diagnostic features and LED status indicators for efficient troubleshooting and real-time monitoring of communication health. Typical Applications The CCC30-2-P 3BDH000549R2 is primarily used in process automation systems across various industries, including oil and gas, power generation, water treatment, and manufacturing. It serves as a vital link, enabling the main controller to communicate with and manage a diverse array of field equipment and peripheral systems.
interface *Output method: rear output *Fast Ethernet: 3 slots, each slot supports 8 ports, with optional optical and electrical options *Gigabit Ethernet: Provides 4 1000Base SFP slots *CONSOLE port: RS232 (RJ45) *Alarm port: 5.08mm spacing 3-pin Phoenix wiring terminal, 250VAC/220VDC 2 A cable *Twisted pair cable: 100m *Multimode fiber: 1310nm, 2km (100Mbps); 1310nm, 500m (gigabit) *Single mode fiber: 1310nm, 0-40km; 1550nm, 0-80km source *Input voltage: 110-220VDC/VAC, redundant input *Connection terminal: 5.08mm spacing 5-pin Phoenix wiring terminal *Power:<40W mechanical properties *Case: Aluminum model with fanless design *Protection level: IP30 *Installation method: 19 inch 1U rack type *Shell size: 440 mm * 44.5 mm * 370 mm (W * H * D), as shown in the attached image *Impact, vibration, and drop: meet the requirements of IEC61850-3 5.5 CM level *Weight: approximately 4.3kg
