BENTLY 125680-01: Industrial Control Module for Precision Applications

No.937988
Engineered for precision control applications, the BENTLY 125680-01 module offers unparalleled accuracy and reliability, making it an essential component in demanding industrial environments.
  • BENTLY 125680-01: Industrial Control Module for Precision Applications
  • BENTLY 125680-01: Industrial Control Module for Precision Applications
  • BENTLY 125680-01: Industrial Control Module for Precision Applications
  • BENTLY 125680-01: Industrial Control Module for Precision Applications
  • Description

  • Here's how it works

  • SPECIFICATION

Operating Voltage:220 V

Output Frequency:30 kHz

Certified Product:Yes

Series:125680-01

Material Coding:Unique proprietary materials for enhanced durability and performance

    The BENTLY 125680-01 module is meticulously designed for industries requiring high-precision control systems. Its robust construction and advanced technology ensure seamless integration into complex machinery, enhancing operational efficiency.

    Equipped with cutting-edge signal processing capabilities, this module delivers precise control signals with minimal distortion, guaranteeing accurate performance even under varying environmental conditions.

    Crafted from unique proprietary materials, the BENTLY 125680-01 is built to withstand the rigors of industrial use, offering extended lifespan and superior reliability compared to conventional modules.

    User-friendly installation and maintenance procedures minimize downtime, ensuring continuous operation without the need for frequent repairs or replacements.

    Comprehensive compatibility with leading industrial automation systems ensures easy integration, allowing for streamlined system management and optimization across different platforms.

BENTLY 125680-01

BENTLY 125680-01

interface
*Output method: rear output
*Fast Ethernet: 3 slots, each slot supports 8 ports, with optional optical and electrical options
*Gigabit Ethernet: Provides 4 1000Base SFP slots
*CONSOLE port: RS232 (RJ45)
*Alarm port: 5.08mm spacing 3-pin Phoenix wiring terminal, 250VAC/220VDC 2 A
cable
*Twisted pair cable: 100m
*Multimode fiber: 1310nm, 2km (100Mbps); 1310nm, 500m (gigabit)
*Single mode fiber: 1310nm, 0-40km; 1550nm, 0-80km
source
*Input voltage: 110-220VDC/VAC, redundant input
*Connection terminal: 5.08mm spacing 5-pin Phoenix wiring terminal
*Power:<40W
mechanical properties
*Case: Aluminum model with fanless design
*Protection level: IP30
*Installation method: 19 inch 1U rack type
*Shell size: 440 mm * 44.5 mm * 370 mm (W * H * D), as shown in the attached image
*Impact, vibration, and drop: meet the requirements of IEC61850-3 5.5 CM level
*Weight: approximately 4.3kg
*10 Mbps forwarding speed: 14881pps
*100Mbps forwarding speed: 148810pps
*Transmission method: storage and forwarding
*System exchange bandwidth: 1.6Gbps
*Cache size: 1Mbits
*MAC address table: 2K
