Bently Nevada 3500/42-01-00 Monitor Module IN STOCK

Brand: Bently Nevada (Emerson)
Model: 3500/42-01-00
Order Number: 3500/42-01-00
Product Name: 4-Channel Proximitor/Seismic Monitor Module
Place of Origin: USA
Customs Code: HS 85371090
Dimensions: 241.3 mm × 24.4 mm × 241.8 mm
$432.00
  • Bently Nevada 3500/42-01-00 Monitor Module IN STOCK
  • Description

  • Here's how it works

  • SPECIFICATION

Bently Nevada 3500/42-01-00
Brand: Bently Nevada (Emerson)
Model: 3500/42-01-00
Order Number: 3500/42-01-00
Product Name: 4-Channel Proximitor/Seismic Monitor Module
Place of Origin: USA
Customs Code: HS 85371090
Dimensions: 241.3 mm × 24.4 mm × 241.8 mm

Weight: 0.82 kg (net)
Temperature: Operating -40°C to +70°C; Storage -40°C to +85°C
Electrical: Supply 24 VDC (18–32 VDC); Power 7.7 W; 4 differential inputs; Sensitivity 3.94–7.87 mV/μm; 24-bit ADC; Isolation 1.5 kV DC
Key Features: Radial vibration, axial thrust, displacement monitoring; TMR compatible; User-programmable channels; Alarm thresholds; OK/Alarm LED diagnostics; API 670 compliant
Application Cases
1. Gas Turbine Monitoring: Critical vibration and thrust monitoring for power generation gas turbines, preventing catastrophic failures.
2. Centrifugal Compressors: Axial and radial vibration protection for oil & gas pipeline compressors.
3. Steam Turbine Generators: Continuous monitoring of turbine shafts, bearings, and casings in utility power plants.
interface
*Output method: rear output
*Fast Ethernet: 3 slots, each slot supports 8 ports, with optional optical and electrical options
*Gigabit Ethernet: Provides 4 1000Base SFP slots
*CONSOLE port: RS232 (RJ45)
*Alarm port: 5.08mm spacing 3-pin Phoenix wiring terminal, 250VAC/220VDC 2 A
cable
*Twisted pair cable: 100m
*Multimode fiber: 1310nm, 2km (100Mbps); 1310nm, 500m (gigabit)
*Single mode fiber: 1310nm, 0-40km; 1550nm, 0-80km
source
*Input voltage: 110-220VDC/VAC, redundant input
*Connection terminal: 5.08mm spacing 5-pin Phoenix wiring terminal
*Power:<40W
mechanical properties
*Case: Aluminum model with fanless design
*Protection level: IP30
*Installation method: 19 inch 1U rack type
*Shell size: 440 mm * 44.5 mm * 370 mm (W * H * D), as shown in the attached image
*Impact, vibration, and drop: meet the requirements of IEC61850-3 5.5 CM level
*Weight: approximately 4.3kg
*10 Mbps forwarding speed: 14881pps
*100Mbps forwarding speed: 148810pps
*Transmission method: storage and forwarding
*System exchange bandwidth: 1.6Gbps
*Cache size: 1Mbits
*MAC address table: 2K
