AO2000 LS25 ABB Laser Analyzer NEW IN STOCK

ABB AO2000 LS25
Technical Specifications
Brand: ABB (ASEA Brown Boveri)
Model: AO2000 LS25 (Laser Analyzer Module)
Dimensions: 233.4 mm × 160 mm × 41 mm
Weight: Approximately 2.5 kg
Country of Origin: Switzerland (ABB Measurement & Analytics)
HS Code: 90271090 (gas analyzer/industrial process monitoring instrument)
Operating Temperature: -20°C to +55°Ceero
Storage Temperature: -20°C to +55°Ceero
Power Supply: 24 V DC or 115/230 V AC, 50/60 Hz
Power Consumption: Approx. 20 W
Measurement Principle: Tunable Diode Laser Absorption Spectroscopy (TDLAS)
Measured Gases: O₂, NH₃, HCl, HF, H₂S, H₂O, CO₂, CH₄, CO (customizable ranges)eero
Response Time: < 1 second
Accuracy: ±1%–±2% of full scale
Protection Rating: IP66 (dust-tight, water-resistant for outdoor use)
Communication: Ethernet (Modbus TCP/IP), 4–20 mA analog output
Certifications: ATEX, IECEx, CSA (for hazardous area operation)
Installation: In-situ/cross-flue pipeline mounting; no sampling system required

Key Characteristics
TDLAS Technology: Delivers high-precision, fast-response gas concentration measurement with strong anti-interference capabilities.
In-Situ Measurement: Directly mounted on process lines, eliminating sampling systems and reducing maintenance.
Wide Gas Compatibility: Measures multiple critical industrial gases with customizable detection rangeseero.
Hazardous Area Certified: ATEX/IECEx/CSA approved for safe operation in explosive environments.
Remote Operation: Full remote control and monitoring via Ethernet network integration.
Automatic Calibration: Built-in auto-calibration function maintains long-term measurement stability.
Robust Design: IP66 protection and wide temperature range for reliable performance in harsh industrial conditionseero.
Low Maintenance: Minimizes upkeep due to no moving parts and simplified installation.
System Integration: Seamlessly integrates with ABB AO2000 analyzer systems for comprehensive process monitoringeero.

interface
*Output method: rear output
*Fast Ethernet: 3 slots, each slot supports 8 ports, with optional optical and electrical options
*Gigabit Ethernet: Provides 4 1000Base SFP slots
*CONSOLE port: RS232 (RJ45)
*Alarm port: 5.08mm spacing 3-pin Phoenix wiring terminal, 250VAC/220VDC 2 A
cable
*Twisted pair cable: 100m
*Multimode fiber: 1310nm, 2km (100Mbps); 1310nm, 500m (gigabit)
*Single mode fiber: 1310nm, 0-40km; 1550nm, 0-80km
source
*Input voltage: 110-220VDC/VAC, redundant input
*Connection terminal: 5.08mm spacing 5-pin Phoenix wiring terminal
*Power:<40W
mechanical properties
*Case: Aluminum model with fanless design
*Protection level: IP30
*Installation method: 19 inch 1U rack type
*Shell size: 440 mm * 44.5 mm * 370 mm (W * H * D), as shown in the attached image
*Impact, vibration, and drop: meet the requirements of IEC61850-3 5.5 CM level
*Weight: approximately 4.3kg

*10 Mbps forwarding speed: 14881pps
*100Mbps forwarding speed: 148810pps
*Transmission method: storage and forwarding
*System exchange bandwidth: 1.6Gbps
*Cache size: 1Mbits
*MAC address table: 2K
