ABB REF615 HBFDACADABCIANN2XE - Advanced Industrial Control Module

No.937251
The ABB REF615 HBFDACADABCIANN2XE is an advanced industrial control module designed for high-performance automation tasks in demanding environments. It seamlessly integrates into complex systems, offering precision, reliability, and efficiency.
  • ABB REF615 HBFDACADABCIANN2XE - Advanced Industrial Control Module
  • ABB REF615 HBFDACADABCIANN2XE - Advanced Industrial Control Module
  • ABB REF615 HBFDACADABCIANN2XE - Advanced Industrial Control Module
  • ABB REF615 HBFDACADABCIANN2XE - Advanced Industrial Control Module
  • Description

  • Here's how it works

  • SPECIFICATION

Operating Voltage:220 V

Output Frequency:30 kHz

Certified Product:Yes

Series:REF615 HBFDACADABCIANN2XE

Brand:ABB

Model:REF615 HBFDACADABCIANN2XE

    This cutting-edge module from ABB is tailored for industrial automation systems, boasting a robust design and precise control capabilities.

    It is equipped with advanced circuitry that ensures high reliability and long operational life, even under challenging conditions.

    The REF615 HBFDACADABCIANN2XE supports seamless integration with existing ABB and third-party systems, facilitating easy implementation and maintenance.

    Featuring a compact size and versatile mounting options, this module optimizes space and enhances system flexibility.

    Designed with user-friendly interfaces, it provides intuitive setup and monitoring, allowing technicians to manage complex operations efficiently.

ABB REF615 HBFDACADABCIANN2XE

ABB REF615 HBFDACADABCIANN2XE

interface
*Output method: rear output
*Fast Ethernet: 3 slots, each slot supports 8 ports, with optional optical and electrical options
*Gigabit Ethernet: Provides 4 1000Base SFP slots
*CONSOLE port: RS232 (RJ45)
*Alarm port: 5.08mm spacing 3-pin Phoenix wiring terminal, 250VAC/220VDC 2 A
cable
*Twisted pair cable: 100m
*Multimode fiber: 1310nm, 2km (100Mbps); 1310nm, 500m (gigabit)
*Single mode fiber: 1310nm, 0-40km; 1550nm, 0-80km
source
*Input voltage: 110-220VDC/VAC, redundant input
*Connection terminal: 5.08mm spacing 5-pin Phoenix wiring terminal
*Power:<40W
mechanical properties
*Case: Aluminum model with fanless design
*Protection level: IP30
*Installation method: 19 inch 1U rack type
*Shell size: 440 mm * 44.5 mm * 370 mm (W * H * D), as shown in the attached image
*Impact, vibration, and drop: meet the requirements of IEC61850-3 5.5 CM level
*Weight: approximately 4.3kg
*10 Mbps forwarding speed: 14881pps
*100Mbps forwarding speed: 148810pps
*Transmission method: storage and forwarding
*System exchange bandwidth: 1.6Gbps
*Cache size: 1Mbits
*MAC address table: 2K
