ABB 216DB61 HESG324063R100/J: Advanced Industrial Control Module

No.934323
The ABB 216DB61 HESG324063R100/J is an advanced industrial control module designed for precise and reliable operation in demanding environments. Ideal for applications requiring high performance and efficiency.
  • ABB 216DB61 HESG324063R100/J: Advanced Industrial Control Module
  • ABB 216DB61 HESG324063R100/J: Advanced Industrial Control Module
  • ABB 216DB61 HESG324063R100/J: Advanced Industrial Control Module
  • ABB 216DB61 HESG324063R100/J: Advanced Industrial Control Module
  • Description

  • Here's how it works

  • SPECIFICATION

Place of Origin:Sweden

Order Number:216DB61 HESG324063R100/J

Brand:ABB

Model:216DB61 HESG324063R100/J

Operating Voltage:Up to 690 VAC

Output Frequency:Up to 6 kHz

Certified Product:Yes

Series:ABB Industrial Automation

Item Code:216DB61 HESG324063R100/J

    Innovative design for enhanced efficiency and durability, ensuring consistent performance across a wide range of industrial applications.

    Advanced circuitry for precise control and monitoring, facilitating accurate system operation and diagnostics.

    Robust materials and construction withstand harsh environmental conditions, maximizing uptime and reducing maintenance requirements.

    User-friendly interface for easy setup and configuration, allowing operators to quickly integrate the module into existing systems.

    Comprehensive compatibility with ABB's suite of automation products, enabling seamless integration into larger industrial control networks.

ABB 216DB61 HESG324063R100/J

ABB 216DB61 HESG324063R100/J

interface
*Output method: rear output
*Fast Ethernet: 3 slots, each slot supports 8 ports, with optional optical and electrical options
*Gigabit Ethernet: Provides 4 1000Base SFP slots
*CONSOLE port: RS232 (RJ45)
*Alarm port: 5.08mm spacing 3-pin Phoenix wiring terminal, 250VAC/220VDC 2 A
cable
*Twisted pair cable: 100m
*Multimode fiber: 1310nm, 2km (100Mbps); 1310nm, 500m (gigabit)
*Single mode fiber: 1310nm, 0-40km; 1550nm, 0-80km
source
*Input voltage: 110-220VDC/VAC, redundant input
*Connection terminal: 5.08mm spacing 5-pin Phoenix wiring terminal
*Power:<40W
mechanical properties
*Case: Aluminum model with fanless design
*Protection level: IP30
*Installation method: 19 inch 1U rack type
*Shell size: 440 mm * 44.5 mm * 370 mm (W * H * D), as shown in the attached image
*Impact, vibration, and drop: meet the requirements of IEC61850-3 5.5 CM level
*Weight: approximately 4.3kg
*10 Mbps forwarding speed: 14881pps
*100Mbps forwarding speed: 148810pps
*Transmission method: storage and forwarding
*System exchange bandwidth: 1.6Gbps
*Cache size: 1Mbits
*MAC address table: 2K
