ABB PP883 3BSE092979R1 DCS Touchscreen HMI

ABB PP883 3BSE092979R1 - Product Specification & Description
Brand: ABB
Model: PP883 3BSE092979R1
Product Name: Panel 800 Touchscreen HMI
Dimensions: 340 × 242 × 57 mm (W×H×D); Cut-out: 324 × 226 mm; Mounting depth: 49 mm (149 mm with clearance)
Weight: 2.6 kg (net)
Country of Origin: Sweden/Switzerland
HS Code: 8517.62.9000
Operating Temperature: -10 °C to +60 °C; Relative humidity: 5–85% non-condensing
Storage Temperature: -20 °C to +70 °C

Power Input: 24 V DC (18–32 VDC); Power consumption: 28.8 W max
Display: 12.1" TFT/LED touchscreen; Resolution: 1280 × 800 pixels; Brightness: 400 cd/m²; Resistive touch interaction
Memory: 1 GB main memory; 2 GB SSD (1.5 GB free for application storage); SD card slot for external storage
Communication Interfaces:
- 2 x shielded RJ45 ports (10/100 Base-T Ethernet)
- 2 x USB 2.0 ports (500 mA each)
- 1 x RS232, 1 x RS422/485, 1 x RS485 (COM2 configurable)
Key Features:
- Robust diecast aluminum housing with powder coating; Front protection: IP65, NEMA 4X/12, UL Type 4X/12; Rear protection: IP20
- High-resolution vector-based graphics with icon-based interface, navigation, and control
- Panel Builder 800 tool with Windows-like environment, multi-language support, and preconfigured templates/libraries for rapid engineering
- Built-in real-time clock; Display dimming capability; Vibration/shock resistance: 1 G / 15 G
- Open architecture with .NET framework support; Multi-brand controller connectivity; Application simulation before deployment
Certifications: CE, FCC, KCC, UL 61010-2-201, Marine (DNV, KR, GL, LR, ABS, CCS), RoHS (2011/65/EU), WEEE (2012/19/EU)
Core Functions: Real-time process visualization and control for industrial automation systems; Intuitive operator interaction; Secure data storage and configuration; Seamless integration with ABB System 800xA and third-party controllers
Typical Applications: Manufacturing, power generation, oil & gas, chemical processing, and water/wastewater; Ideal for harsh industrial environments requiring reliable HMI operation

interface
*Output method: rear output
*Fast Ethernet: 3 slots, each slot supports 8 ports, with optional optical and electrical options
*Gigabit Ethernet: Provides 4 1000Base SFP slots
*CONSOLE port: RS232 (RJ45)
*Alarm port: 5.08mm spacing 3-pin Phoenix wiring terminal, 250VAC/220VDC 2 A
cable
*Twisted pair cable: 100m
*Multimode fiber: 1310nm, 2km (100Mbps); 1310nm, 500m (gigabit)
*Single mode fiber: 1310nm, 0-40km; 1550nm, 0-80km
source
*Input voltage: 110-220VDC/VAC, redundant input
*Connection terminal: 5.08mm spacing 5-pin Phoenix wiring terminal
*Power:<40W
mechanical properties
*Case: Aluminum model with fanless design
*Protection level: IP30
*Installation method: 19 inch 1U rack type
*Shell size: 440 mm * 44.5 mm * 370 mm (W * H * D), as shown in the attached image
*Impact, vibration, and drop: meet the requirements of IEC61850-3 5.5 CM level
*Weight: approximately 4.3kg

*10 Mbps forwarding speed: 14881pps
*100Mbps forwarding speed: 148810pps
*Transmission method: storage and forwarding
*System exchange bandwidth: 1.6Gbps
*Cache size: 1Mbits
*MAC address table: 2K
