ABB EL3000 Series Product Introduction & Technical Parameters
Brand: ABB Measurement & Analytics
Model: EL3000 Series (Including EL3020, EL3040)
Product Name: Continuous Gas Analyzer / Flue Gas Analysis System

Dimensions
EL3020 (19" rack): 483 mm (W) × 357 mm (D) × 132 mm (H) (3 RU, 4 RU with Magnos27)
EL3040 (wall-mount): 360 mm (W) × 230 mm (D) × 404 mm (H)
Weight
EL3020: 7–15 kg
EL3040: 13–21 kg
Country of Origin
Switzerland (Manufactured by ABB Measurement & Analytics)
HS Code (Customs Code)
8901.90.00 (Gas analysis/instrumentation apparatus; exact 8-digit may vary by region; common classification: 8543.70.90 for electrical analytical instruments)
Temperature & Humidity
Operating Temperature: EL3020 5–45 °C; EL3040 5–40 °C (with FID/ZO23); Storage: -25–65 °C
Relative Humidity: <75% non-condensing
Altitude: Max 2000 m (on request for higher)
Input
Power Supply: 100–240 V AC, -15/+10%, 50–60 Hz ±3 Hz (max 187 VA); Analyzer modules: 24 V DC ±5%
Sample Gas Inlet: Flow 20–100 L/h (typical); Absolute pressure 800–1250 hPa (on request 600–1600 hPa)
Digital Inputs: Configurable isolated binary inputs (via optional I/O modules)
Communication Inputs: Ethernet (Modbus TCP), Modbus RTU (RS-485), PROFIBUS-DP (optional)
Output
Display: 240×160 pixel backlit graphical LCD; up to 5 measured values simultaneous
Analog Outputs: 4–20 mA (configurable per measurement range)
Digital Outputs: Relay contacts (NO/NC, configurable via optional I/O modules)
Communication Outputs: Ethernet (Modbus TCP), Modbus RTU (RS-485), PROFIBUS-DP (optional)
Status Outputs: Alarms via digital outputs; self-diagnostics via display/communication
Key Features
Modular Design: Interchangeable modules for CO, CO₂, NO, NO₂, SO₂, O₂, hydrocarbons, trace O₂, etc.
Calibration: Air/integral cell calibration (no test gas cylinders); automatic pump/valve control; annual calibration recommended
Measurement Accuracy: Linearity error ≤0.5–1% of span; repeatability ≤0.5–1% of span; zero drift ≤1–3% of span/week
Self-Diagnostics: Real-time status; maintenance alerts; fault logging; auto-range for measurement ranges
Enclosure: EL3020 IP20 (IP40 for emission monitoring); EL3040 IP65; ATEX II 3G (non-flammable gas version)
Compliance: EN 61010, EN 61326, EN 15267 (emission); optional QAL3 (EN 14181)
Integration: Configurable I/O; Ethernet/fieldbus connectivity; remote access via web server
Material: Wetted parts stainless steel 1.4305/1.4571, FPM/PTFE/FFKM gaskets; corrosion-resistant for harsh environment
