ABB DSMC-112 57360001-HC Brand ABB Model DSMC-112 Order Number 57360001-HC Product Name Floppy Disk Controller Module Origin Sweden HS Code 85389091 Dimensions Approx. 240mm × 15mm × 240mm Weight Approx. 0.46kg Operating Temperature Working Temperature: -25°C to +60°C Storage Temperature: -40°C to +85°C Voltage Supply Voltage: 24VDC Current Operating current: ≤0.15A, power consumption: approx. 2.5W Features Specialized floppy disk control module for ABB MasterView 800 control system Supports stable data reading and writing, and reliable program storage transmission Equipped with standard communication interfaces, compatible with system backplane data interaction Wide operating temperature range, adaptable to harsh industrial working environments Compact module structure, convenient for system installation and hardware replacement Stable performance, low power consumption, and strong anti-electromagnetic interference ability
interface *Output method: rear output *Fast Ethernet: 3 slots, each slot supports 8 ports, with optional optical and electrical options *Gigabit Ethernet: Provides 4 1000Base SFP slots *CONSOLE port: RS232 (RJ45) *Alarm port: 5.08mm spacing 3-pin Phoenix wiring terminal, 250VAC/220VDC 2 A cable *Twisted pair cable: 100m *Multimode fiber: 1310nm, 2km (100Mbps); 1310nm, 500m (gigabit) *Single mode fiber: 1310nm, 0-40km; 1550nm, 0-80km source *Input voltage: 110-220VDC/VAC, redundant input *Connection terminal: 5.08mm spacing 5-pin Phoenix wiring terminal *Power:<40W mechanical properties *Case: Aluminum model with fanless design *Protection level: IP30 *Installation method: 19 inch 1U rack type *Shell size: 440 mm * 44.5 mm * 370 mm (W * H * D), as shown in the attached image *Impact, vibration, and drop: meet the requirements of IEC61850-3 5.5 CM level *Weight: approximately 4.3kg
