95DSS3-1CEXSS FIREYE SCANNER

95DSS3-1CEXSS Fireye Scanner Technical Parameters
Brand: Fireye
Model: 95DSS3-1CEXSS (Fireye Scanner)
Dimensions: Compact form factor optimized for flame detection applications, with specific dimensions of 10.03 × 5.28 × 5.28 inches (255 × 134 × 134 mm), designed to fit seamlessly into various industrial combustion system setups and compatible with standard mounting configurations
Weight: Approximately 1.8 kg (3.97 lbs) per unit, featuring a robust yet lightweight design that facilitates easy installation and handling without adding excess load to connected combustion equipment
Origin: Manufactured in the United States, adhering to Fireye’s global quality control standards for industrial flame detection and scanner products
HS Code: 90275090 (classified under industrial flame detection instruments and scanners, compliant with international trade classification standards for physical and chemical analysis equipment)
Temperature: Operating temperature range: -40°C to +85°C, suitable for harsh industrial combustion environments; storage temperature range: -55°C to +100°C, ensuring stable performance during long-term storage without degradation; rated temperature class T6 for compatibility with high-temperature combustion scenarios
Input: 24V DC power supply input; dual UV and IR sensors for flame detection; compatible with industrial combustion system signals; supports connection to burner management systems (BMS) with standard interfaces; electronic self-check function without mechanical shutters

Output: Two independently adjustable flame relays (FR1 and FR2) operable from UV sensor, IR sensor, or both; two 4-20 mA analog signal outputs (one for each flame relay) for real-time flame intensity feedback; fault relay output for flame loss, sensor failure, and power anomalies; configurable on/off thresholds for flame detection
Features: Integrated UV and IR dual sensors for high-accuracy flame discrimination, detecting flame “flicker” characteristics for reliable identification; no separate amplifier or flame switch module required, integrating all functions into a single unit; factory-installed 95DISP-1-SS alpha-numeric VFD display and keypad for easy parameter configuration and status monitoring; 316 stainless steel housing with IP66 ingress protection, suitable for extreme industrial and marine combustion environments; ATEX ExdIIC T6 and FM Class I Div 2 certifications for hazardous area applications; electronic self-diagnostic function for sensor faults, power issues, and flame loss, with visual status indicators; quick-disconnect cable connections for easy installation and maintenance; compatible with Fireye Explorer software and various industrial burner management systems; 21 selectable modulation frequencies for optimal flame discrimination; four programmable files for different fuels or firing rates; compliant with international industrial safety standards and EU RoHS directive

interface
*Output method: rear output
*Fast Ethernet: 3 slots, each slot supports 8 ports, with optional optical and electrical options
*Gigabit Ethernet: Provides 4 1000Base SFP slots
*CONSOLE port: RS232 (RJ45)
*Alarm port: 5.08mm spacing 3-pin Phoenix wiring terminal, 250VAC/220VDC 2 A
cable
*Twisted pair cable: 100m
*Multimode fiber: 1310nm, 2km (100Mbps); 1310nm, 500m (gigabit)
*Single mode fiber: 1310nm, 0-40km; 1550nm, 0-80km
source
*Input voltage: 110-220VDC/VAC, redundant input
*Connection terminal: 5.08mm spacing 5-pin Phoenix wiring terminal
*Power:<40W
mechanical properties
*Case: Aluminum model with fanless design
*Protection level: IP30
*Installation method: 19 inch 1U rack type
*Shell size: 440 mm * 44.5 mm * 370 mm (W * H * D), as shown in the attached image
*Impact, vibration, and drop: meet the requirements of IEC61850-3 5.5 CM level
*Weight: approximately 4.3kg

*10 Mbps forwarding speed: 14881pps
*100Mbps forwarding speed: 148810pps
*Transmission method: storage and forwarding
*System exchange bandwidth: 1.6Gbps
*Cache size: 1Mbits
*MAC address table: 2K
